卡特零件查询（730） 441-2727: KIT-MIRROR
广数供应链运营团队, 15 02月, 2025，浏览：
241 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8T-4137M | [3] | BOLT(M10X1.5X20-MM) | |
| 2. | 8T-4121 | [3] | WASHER-HARD(11X21X2.5-MM THK) | |
| 3. | 3S-2093 | [36] | STRAP-CABLE | |
| 4. | 8T-8729 | [10] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| 5. | 208-4540Y | [1] | HARNESS AS-WIRING(HEATED MIRROR)(RH) | |
| 6. | 236-5334 | [1] | WIRE AS | |
| 7. | 271-2824 | [1] | SWITCH AS-ROCKER(HEATED MIRROR) | |
| 8. | 327-7732 | [1] | MIRROR AS-CONVEX | |
| | 326-8729 | [1] | COVER AS-REAR | |
| 9. | 328-1905Y | [1] | HARNESS AS-WIRING(HEATED MIRROR)(LH) | |
| 10. | 353-3585 | [1] | MIRROR-CONVEX(RH) | |
| 11. | 353-3587 | [1] | MIRROR-CONVEX(LH) | |
| 12. | 373-1753 | [1] | MIRROR-REAR VIEW(POWER, HEATED, LH) | |
| 13. | 373-1754 | [1] | MIRROR-REAR VIEW(POWER, HEATED, RH) | |
| 14. | 102-8802 | [2] | KIT-RECEPTACLE(2-PIN) | |
| 15. | 102-8805 | [1] | KIT-RECEPTACLE(6-PIN) | |
| | | | (EACH RECEPTACLE KIT INCLUDES RECEPTACLE AS & WEDGE) |
| 16. | 438-6751 | [4] | CONNECTOR AS | |
| 17. | 4P-7581 | [4] | CLIP(LADDER) | |
| 18. | 4P-8134 | [5] | CLIP(LADDER) | |
| 19. | 5P-9085 | [2] | CLIP(LOOP) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
