纽荷兰零件查询(EH130) - CRAWLER EXCAVATOR (3/04-) (09 -05[00]) - COUNTERWEIGHT (GUARDS) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
172 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY21C00007F3 | [1] | GUARD ASSY. | KOB |
| 1. | HS18C10025G1 | [4] | SCREW | KOB Superseded by part number: ZS18C10025 |
| 2. | YT21C01172P1 | [4] | LOCK WASHER | KOB |
| 3. | HY25X11024G1 | [4] | WASHER | KOB |
| 4. | YT21C01187P1 | [4] | WASHER | KOB Superseded by part number: YT21C01187P2 |
| 5. | ZM32C12030 | [2] | BOLT | KOB |
| 6. | YY21C01060P1 | [1] | GUARD | KOB |
| 7. | YY21C01045F3 | [1] | GUARD ASSY. | KOBIncl. 8 - 16 |
| 8. | YT21C01090F2 | [1] | LOCK | KOBIncl. 9, 10 |
| 9. | YR22C01025P1 | [1] | LOCK | KOB Superseded by part number: YR22C01025P2 |
| 10. | YT21C01136P1 | [1] | PLATE | KOB |
| 11. | YY21C01272P1 | [1] | GUARD | KOB |
| 12. | YX21C01056P1 | [2] | HINGE | KOB |
| 13. | YT21C01354P1 | [1] | STAY | KOBSTAY |
| 14. | ZW16X08000 | [1] | WASHER | KOB |
| 15. | 2419R9D2 | [1] | COTTER PIN | KOB |
| 16. | YR21C01123P1 | [1] | COLLAR | KOB |
