纽荷兰零件查询(EH80) - MIDI CRAWLER EXCAVATOR ASN LF04-02000 (N4TA18001 thru N4TA18010, ASN N5TA18011 -) (NA) (1/ (182) - CYLINDER ASSEMBLY, BOOM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
338 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF01V00005F1 | [1] | CYLINDER | KOBBOOM, Incl. 1 - 50 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTUBE, CYLINDER |
| 3. | YT01V00017S003 | [1] | CYLINDER HEAD | KOB |
| 4. | YT01V00017S004 | [1] | BUSHING | KOB |
| 5. | 2438U721S7 | [1] | SNAP RING | KOB |
| 6. | YT01V00017S006 | [1] | RING | KOB |
| 7. | 2438U721S16 | [1] | RING | KOB |
| 8. | YT01V00001S009 | [1] | RING | KOB |
| 9. | ZD12G10500 | [2] | O-RING,104.40mm ID x 110.60mm OD x 3.10mm | KOBO-RING |
| 10. | PY01V00036S008 | [1] | RING | KOB |
| 11. | ZD11G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOB |
| 12. | LF01V00005S012 | [1] | HOLDER | KOB |
| 13. | YT01V00017S013 | [2] | SEAL | KOB |
| 14. | YT01V00017S014 | [1] | COLLAR | KOB |
| 15. | 2438U1949S12 | [2] | RING | KOB |
| 16. | YT01V00017S016 | [1] | BEARING | KOB |
| 17. | YT01V00017S017 | [1] | PISTON | KOBPISTON |
| 18. | 2438U716S23 | [1] | SEAL | KOBSEALRING RING, SEAL |
| 20. | YM01V00009S020 | [1] | NUT | KOB |
| 21. | 2438U999S21 | [1] | SET SCREW | KOB |
| 22. | 2436U330S16 | [1] | BALL | KOB |
| 23. | YT01V01001P2 | [2] | BUSHING | KOBBUSHING |
| 24. | 2438U1946S25 | [2] | RING | KOBRING, WIPER |
| 25. | YT01V01003P2 | [2] | BUSHING | KOB |
| 26. | LP01V00007S026 | [2] | RING | KOB |
| 27. | YT01V00001S027 | [2] | BAND | KOBBAND ASSY |
| 28. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 29. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 50. | YT01V00017S050 | [2] | RING | KOB Superseded by part number: YM01V00019S018 |
| . . | LF01V00005R400 | [1] | REPAIR KIT | KOBIncl. 1, 23 |
| . . | LF01V00005R500 | [1] | REPAIR KIT | KOBIncl. 2, 25 |
| . . | YT01V00017R600 | [1] | SEAL KIT | KOBREPAIR KIT PISTON SIDE, Incl. 18, 50 |
| . . | LF01V00005R700 | [1] | REPAIR KIT | KOBREPAIR KIT ALL (ROD+PISTON), Incl. 6 - 11, 13, 15, 18, 50 Superseded by part number: YT01V00017S013, LF01V00005R700M |
