| 1. |
84527492
|
[1] |
LEVER
|
ZED
|
| 2. |
84475227
|
[1] |
ROLLER
|
ZED
|
| 3. |
84344110
|
[1] |
PROFILE
|
ZED
,, Serial Range: -C047
|
| 3. |
47434485
|
[1] |
PROFILE
|
ZED
,, Serial Range: -F048106 Superseded by part number: 47739549
|
| 3. |
47739549
|
[1] |
PROFILE
|
ZED
, Start Serial: D107
|
| 4. |
84074735
|
[1] |
ARM
|
ZED
|
| 5. |
84439533
|
[2] |
BALL JOINT HEAD,M10
|
ZED
|
| 6. |
84527535
|
[1] |
SUPPORT
|
ZED
,, Serial Range: -C047
|
| 6. |
47440569
|
[1] |
SUPPORT
|
ZED
,, Serial Range: -F048086
|
| 6. |
47560646
|
[1] |
SUPPORT
|
ZED
, Serial Range: -F087146
|
| 6. |
47871087
|
[1] |
SUPPORT
|
ZED
, Start Serial: D147
|
| 7. |
84817865
|
[1] |
STOP
|
ZED
,, Serial Range: -C047
|
| 7. |
47434440
|
[1] |
ARM
|
ZED
,, Serial Range: -F048106
|
| 7. |
47739552
|
[1] |
STOP
|
ZED
, Start Serial: D107
|
| 8. |
84078516
|
[1] |
WEAR STRIP
|
ZED
|
| 9. |
84800079
|
[1] |
ROD
|
ZED
,, Serial Range: -C047
|
| 9. |
47434555
|
[1] |
ROD
|
ZED
,, Start Serial: D048
|
| 10. |
84485847
|
[1] |
SECTOR
|
ZED
,, Serial Range: -C047
|
| 10. |
47435514
|
[1] |
SECTOR
|
ZED
,, Start Serial: D048
|
| 11. |
84572350
|
[1] |
HANDLE
|
ZED
|
| 12. |
87358125
|
[1] |
LOCK
|
ZED
|
| 13. |
332809
|
[1] |
HANDLE GRIP
|
ZED
|
| 14. |
510375
|
[1] |
SPRING
|
ZED
|
| 15. |
84021175
|
[1] |
SPRING
|
ZED
|
| 16. |
84807411
|
[1] |
THIN NUT,Thin, M10 x 1.5, Cl 04
|
ZED
Superseded by part number: 57039
|
| 17. |
412183
|
[6] |
CARRIAGE BOLT,Short Sq Nk, M10 x 35mm, Cl 8.8
|
DUB
Superseded by part number: 9833222
|
| 18. |
140045
|
[10] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 19. |
100016
|
[10] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 20. |
9839231
|
[6] |
WASHER,11mm ID x 32mm OD x 5mm Thk
|
ZED
|
| 21. |
9839233
|
[1] |
SPACER
|
ZED
|
| 22. |
328754
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 23. |
9839232
|
[1] |
WASHER,13mm ID x 32mm OD x 4mm Thk
|
ZED
|
| 24. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 25. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 26. |
9706703
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 27. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 28. |
9706755
|
[2] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 29. |
86977792
|
[1] |
SLOTTED PIN,5mm OD x 40mm L, Slotted
|
ZED
|
| 30. |
14607370
|
[1] |
ROLL PIN,M8 x 45, Slotted
|
MKT
|
| 31. |
443434
|
[1] |
LOCK WASHER,20.5mm ID x 29mm OD x 1mm Thk
|
ZED
|
| 32. |
370024
|
[1] |
CIRCLIP,M20, Ext
|
NH
|
| 33. |
9838305
|
[3] |
WASHER,26mm ID x 38mm OD x 2.27mm Thk
|
ZED
|
| 34. |
140229
|
[3] |
WASHER
|
ZED
|
| 35. |
370002
|
[1] |
CIRCLIP,M25, External
|
NH
|
| 36. |
84334564
|
[1] |
HEX SOC SCREW,FLAT, M10 x 40mm, Cl 12.9
|
ZED
|
| 37. |
350459
|
[1] |
CARRIAGE BOLT,Rnd Head, M10 x 1.5 x 50mm, Full Thd, Cl 8.8
|
ZED
|
| 38. |
300368
|
[4] |
SPRING,10.199mm ID x 20mm OD x 1.1mm Thk
|
ZED
|
| 39. |
86625253
|
[5] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
| 40. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 41. |
412189
|
[1] |
CARRIAGE BOLT,Short Sq Nk, M10 x 1.5 x 80mm, Cl 8.8
|
GI
|
| 42. |
140042
|
[1] |
WASHER,11mm ID x 34mm OD x 3mm Thk
|
GI
|
| 43. |
84520548
|
[1] |
BALL JOINT HEAD,M10
|
ZED
,, Start Serial: D048
|
| 44. |
86529981
|
[1] |
NUT,Hex, M10 x 1.5, LH Thd, Cl 8.8
|
ZED
,, Serial Range: -F048106
|
| 44. |
47470565
|
[1] |
NUT
|
ZED
, Start Serial: D107
|
| 45. |
374892
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
, Start Serial: D092
|
| 47. |
47697404
|
[1] |
STOP
|
ZED
, Start Serial: D107
|
| 53. |
47864003
|
[2] |
PLATE
|
ZED
, Start Serial: D147
|
| 54. |
47864006
|
[2] |
PLATE
|
ZED
, Start Serial: D147
|
