卡特零件查询（730） 237-5512: WARNING GP-BACKUP
广数供应链运营团队, 15 02月, 2025，浏览：
471 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3S-2093 | [3] | STRAP-CABLE | |
| 2. | 213-9100 | [1] | ALARM AS(BACKUP) | |
| | 5P-5623BD | | WIRE-ELECTRICAL(16-GA, BLACK) | |
| | 186-3735 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 9X-1813E | | SLEEVE(31-CM) | |
| 3. | 260-0161CY | [2] | LAMP GP-FLOOD(24-VOLT)(REAR) | |
| 4. | 4P-7581 | [1] | CLIP(LADDER) | |
| 5. | 8T-4121 | [4] | WASHER-HARD(11X21X2.5-MM THK) | |
| 6. | 8T-4133M | [2] | NUT(M10X1.5-THD) | |
| 7. | 8T-4195M | [2] | BOLT(M10X1.5X30-MM) | |
| | B | | USE AS REQUIRED |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | D | | ORDER BY THE METER |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
