| . . | 24100J4973F5 | [1] | CONTROL ASSY, Serial Range: LE4403-LE4636 | |
| . . | 24100J4973F7 | [1] | CONTROL ASSY, Serial Range: LE4637-LE4895 | |
| . . | 24100J4973F9 | [1] | CONTROL ASSY, Start Serial: LE4896 | |
| 3. | 2416T10933 | [1] | SUPPORT | |
| 6. | 2416P7201 | [1] | STAND, SEAT, Serial Range: LE4403-LE4636 | STAND, SEAT, Serial Range: LE4403-LE4636 |
| 7. | ZM11C10025 | [6] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 11. | ZN16C16010 | [2] | NUT | KOB |
| 12. | ZW16X16000 | [1] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 13. | 2417R63 | [1] | SPRING | KOB |
| 14. | 2419T3603 | [1] | PIN SHAFT | PIN SHAFT |
| 18. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 19. | 2416Z312D17 | [2] | SHEET, RUBBER | SHEET, RUBBER |
| 20. | ZP15K02020 | [2] | SPLIT PIN | KOB |
| 21. | 24100N2792F1 | [1] | SUPPORT ASSY | SUPPORT ASSY |
| 21-1. | 2416P7220 | [1] | SUPPORT | SUPPORT |
| 21-2. | 2414P2906 | [1] | COVER | KOB |
| 21-3. | 2414T1973 | [1] | COVER | COVER |
| 21-4. | ZS31C05014 | [6] | SCREW,Phillips Drive, Pan HD, M5 x 14mm | KOBM05x0.8x14mm |
| 21-5. | ZW11P05000 | [6] | WASHER | KOB Superseded by part number: ZW16P05000 |
| 22. | ZS18C08014 | [4] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm |
| 23. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 24. | 2416N2771 | [1] | SUPPORT, Serial Range: LE4403-LE4895 | SUPPORT, Serial Range: LE4403-LE4895 |
| 25. | 2479Z892 | [1] | SWITCH | KOB, Serial Range: LE4403-LE4636 |
| 27. | ZS31C03014 | [4] | SCREW,Phillips Drive, Pan HD, M3 x 14mm | KOBM03x0.5x14mm, Serial Range: LE4403-LE4636 |
| 28. | ZN11C03003 | [2] | NUT | KOBM03x0.5mm, Serial Range: LE4403-LE4636 |
| 29. | ZW22X03000 | [4] | WASHER | KOB, Serial Range: LE4403-LE4636 |
| 30. | 2420Z699 | [3] | GROMMET | KOB |
| 36. | 2418T5373C2 | [4] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 37. | NSS | [1] | NOT SOLD SEPARAT | CONMAT, FLOOR, Serial Range: LE4403-LE4636 |
| 38. | 2427P18D1 | [1] | TANK | |
| 38-1. | 2444T70D2 | [1] | COUPLING, PIPE | |
| 38-2. | 2418T10389 | [1] | TUBE | |
| 39. | 2448U229F1 | [1] | SEAT | KOB, Serial Range: LE4403-LE4895 |
| 40. | 2418T10657 | [2] | PLATE | |
| 43. | 2416P7247 | [1] | SUPPORT | SUPPORT |
| 46. | ZS13C16110 | [4] | SCREW | KOBM16x2.0x110mm, Serial Range: LE4403-LE4636 |
| . . | ZS13C16100 | [6] | SCREW | KOBM16x2.0x100mm, Start Serial: LE4637 |
| 48. | 24100N2814F2 | [1] | LEVER ASSY, CONTROL | LEVER ASSY, CONTROL |
| 48-3. | 2406P2495D1 | [1] | LEVER, CONTROL | LEVER, CONTROL |
| 48-4. | 2406P2495D2 | [1] | LEVER, CONTROL | LEVER, CONTROL |
| 48-5. | 2406P2496D1 | [1] | PEDAL | KOB |
| 48-6. | 2406P2496D2 | [1] | PEDAL | KOB |
| 48-7. | 4019T12 | [1] | PIN | KOB |
| 48-8. | 4016P16 | [1] | BRACKET | KOB |
| 48-9. | 4018T20 | [2] | SPACER | KOB |
| 48-10. | 4025Z8 | [4] | NEEDLE BEARING | KOB |
| 48-11. | 4045Z8 | [4] | OIL SEAL | KOB |
| 48-12. | 6Z1 | [2] | LEVER | KOB |
| 48-13. | 3611V012 | [1] | WASHER | KOB |
| 48-14. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 48-15. | ZS16C10025 | [4] | SCREW | KOBM10x1.50x25mm Superseded by part number: ZS18C10025 |
| 48-16. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 48-17. | ZS16C10038 | [4] | CAPSCREW | |
| 48-18. | 2406T1678D1 | [1] | LINK | KOB |
| 48-19. | 2406T1678D2 | [1] | LINK | KOB |
| 49. | 2406R203D3 | [2] | CABLE | KOB Superseded by part number: 2406R203D6 |
| 51. | 2422J1384 | [1] | FRAME, UPP | |
| 51-1. | 2422J1383 | [1] | DECK, SIDE | |
| 51-2. | 2416T10830D2 | [1] | BRACKET | |
| 51-3. | 2422T435 | [1] | PLATE | |
| 51-4. | 2416P7197 | [1] | BRACKET | |
| 52. | 24100X1345F2 | [1] | REMOTE-CONTROL ASSY P.722-35, Serial Range: LE4403-LE4636 | |
| 54. | 24100N2790F2 | [1] | SUPPORT ASSY, Serial Range: LE4403-LE4972 | SUPPORT ASSY, Serial Range: LE4403-LE4972 |
| 54-2. | 2414P2905 | [1] | COVER | KOB |
| 54-3. | 2414T1974 | [1] | COVER | |
| 54-4. | 2406P2491 | [1] | LEVER | KOB |
| 54-5. | 2416Z332 | [1] | SHEET | KOB |
| 54-6. | 2417Z252 | [1] | SPRING | KOB |
| 54-7. | 2418T10552D4 | [1] | SPACER | KOB |
| 54-8. | ZR36X00600 | [1] | SNAP RING | KOBE-Ring -- Shaft 06mm x OD 12mm |
| 54-9. | ZS31C05014 | [8] | SCREW,Phillips Drive, Pan HD, M5 x 14mm | KOBM05x0.8x14mm |
| 54-10. | ZW11P05000 | [8] | WASHER | KOB Superseded by part number: ZW16P05000 |
| 54-12. | 2406Z294D3 | [1] | GRIP | KOB |
| 54-16. | 2405U101D1612 | [2] | BUSHING | KOB |
| 54-17. | 2416N2801 | [1] | SUPPORT | |
| 54-18. | 2432T1818 | [1] | CLAMP | CLAMP |
| 54-19. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 54-20. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 54-21. | 2416T11070 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 55. | 2416P7291 | [1] | SUPPORT | KOB, Serial Range: LE4403-LE4636 |
| 56. | 2444Z2256 | [1] | HOSE | HOSE |
| 57. | 2444Z2255 | [2] | CONNECTOR | CONNECTOR |
| 58. | ZC15X05000 | [2] | CLIP | KOB |
| 59. | 2422N786 | [1] | PLATE, FLOOR, Serial Range: LE4403-LE4636 | |
| 60. | 2427R451 | [1] | MAT/ FLOOR, Serial Range: LE4403-LE4636 | |
| 61. | 2427R452 | [1] | MAT/ FLOOR, Serial Range: LE4403-LE4636 | |
| 62. | 2419P1422 | [1] | PIN | PIN |
| 63. | 2422N796 | [1] | PLATE FLOOR, Start Serial: LE4637 | |
| 64. | 2427R464 | [1] | MAT, FLOOR, Start Serial: LE4637 | |
| 65. | 2427R465 | [1] | MAT, FLOOR, Start Serial: LE4637 | |
| 66. | 2427R466 | [1] | MAT, FLOOR, Start Serial: LE4637 | |
| 67. | 2427R467 | [1] | NUT, FLOOR, Start Serial: LE4637 | |
| 69. | 24100X1345F3 | [1] | REMOTE-CONTROL ASSY P. 722-35 LE4, Start Serial: 637 | |
| 70. | 2414P2941 | [1] | GUARU FAN | |
| 71. | ZM11C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 72. | ZW11X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 73. | 2416Z253 | [4] | RUBBER SLEEVE | KOB, Start Serial: LE4637 |
| 74. | 2414T1054 | [4] | COVER | KOB, Start Serial: LE4637 |
| 75. | 2418T9226D1 | [2] | SPACER | KOB, Start Serial: LE4637 |
| 76. | ZN32C16015 | [2] | NUT | KOBM16x2.0mm, Start Serial: LE4637 |
| 77. | R16T0152D2 | [2] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm, Start Serial: LE4637 |
| 78. | 2416P7315 | [1] | STAND, SEAT, Start Serial: LE4637 | |
| 79. | 2416P8514 | [1] | SUPPORT | KOB, Start Serial: LE4637 |
| 80. | 2479Z932 | [1] | SWITCH | KOB, Start Serial: LE4637 |
| 81. | 2414Z265 | [1] | COVER | KOB, Start Serial: LE4637 |
| 82. | ZS31C04030 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 30mm | KOBM04x0.7x30mm, Start Serial: LE4637 |
| 83. | ZN16C04003 | [2] | NUT | KOBM04x0.7mm, Start Serial: LE4637 Superseded by part number: ZN18C04003 |
| 84. | ZW16K04000 | [4] | WASHER | KOBID 04 x OD 08 x Th 0.8mm, Start Serial: LE4637 |
| 85. | 2448U230F1 | [1] | SEAT, Start Serial: LE4896 | SEAT, Start Serial: LE4896 |
| 86. | 2416N3192 | [1] | SUPPORT, Start Serial: LE4896 | SUPPORT, Start Serial: LE4896 |
| 87. | 24100N2790F3 | [1] | SUPPORT ASSY, Start Serial: LE4973 | |
| 87-2. | 2414P2905 | [1] | COVER | KOB |
| 87-3. | 2414T1974 | [1] | COVER | |
| 87-5. | 2416Z332 | [1] | SHEET | KOB |
| 87-6. | 2417Z252 | [1] | SPRING | KOB |
| 87-8. | ZR36X00600 | [1] | SNAP RING | KOBE-Ring -- Shaft 06mm x OD 12mm |
| 87-9. | ZS31C05014 | [8] | SCREW,Phillips Drive, Pan HD, M5 x 14mm | KOBM05x0.8x14mm |
| 87-10. | ZW11P05000 | [8] | WASHER | KOB Superseded by part number: ZW16P05000 |
| 87-12. | 2406Z294D3 | [1] | GRIP | KOB |
| 87-16. | 2405U101D1612 | [2] | BUSHING | KOB |
| 87-18. | 2432T1818 | [1] | CLAMP | CLAMP |
| 87-19. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 87-20. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 87-21. | 2416T11070 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 87-22. | 2416N3193 | [1] | SUPPORT | |
| 87-23. | 2406P2544 | [1] | LEVER | KOB |
