| . . | 24100X1205F4 | [1] | HYDR LINES,UPP | |
| 3. | 2438R186F1 | [1] | RESISTOR | RESISTOR |
| 3-7. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 4. | 2438R187F1 | [2] | VALVE, CHECK | VALVE, CHECK |
| 4-7. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| . . | 2418P7649 | [2] | TUBE | TUBE |
| 17. | ZK23E22008 | [4] | CONNECTOR | |
| 18. | ZK23E22012 | [2] | CONNECTOR | CONNECTOR |
| 19. | ZG22E16000 | [1] | NIPPLE | |
| 20. | 2436R209F1 | [1] | VALVE, CHECK | VALVE, CHECK |
| 27. | ZX21M08062 | [2] | FLEXIBLE HOSE | KOB620mm Long (24-13/32 in) |
| 23. | ZH42X08000 | [2] | 45 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 45° -- (Incls. O-Ring ZD12P01800) |
| 25. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 27. | R44P0089D11 | [2] | COUPLING | KOB Superseded by part number: ZG15F03200 |
| 27-3. | R44P0089D11S3 | [2] | GASKET | KOB |
| 28. | NSS | [4] | NOT SOLD SEPARAT | CONHOSE |
| 32. | ZC15X15000 | [8] | CLIP | |
| 33. | ZC15X03600 | [16] | CLIP | KOB |
| 34. | ZS16C10055 | [1] | CAPSCREW M10x1.50x55mm | CAPSCREW M10x1.50x55mm |
| 35. | ZS23C10035 | [6] | SCREW,Hex Socket Head, M10 x 35mm | KOBM10x1.50x35mm |
| 36. | ZS23C10030 | [16] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 37. | ZN16C10008 | [6] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| . . | ZW22X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 39. | ZW22X10000 | [16] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 42. | 2418U2195 | [1] | TUBE | |
| 43. | 2418U2194 | [1] | TUBE | |
| 44. | 2418P8386 | [1] | TUBE TUBE | TUBE TUBE |
| 45. | 2418T10109 | [1] | TUBE TUBE | TUBE TUBE |
| 46. | 2418P8381 | [1] | TUBE TUBE | TUBE TUBE |
| 47. | 2418P8382 | [1] | TUBE TUBE | TUBE TUBE |
| 48. | 2418P8384 | [1] | TUBE TUBE | TUBE TUBE |
| 49. | 2418P8383 | [1] | TUBE TUBE | TUBE TUBE |
| 50. | ZC26X32014 | [1] | CLAMP | |
| 51. | ZS16C12065 | [1] | SCREW | KOBM12x1.75x65mm Superseded by part number: ZS18C12065 |
| 52. | ZW26X12000 | [3] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 53. | ZC36X32016 | [2] | CLAMP | |
| 54. | ZC36X22011 | [1] | CLAMP | KOBDouble Line -- 75x38x13mm (Ø24mm) |
| 55. | 2418T10099 | [1] | TUBE | |
| 56. | 2418T7003D3 | [2] | FLEXIBLE HOSE | KOB |
| 57. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 58. | 2416P7144 | [1] | SUPPORT | |
| 59. | ZS16C12030 | [2] | CAPSCREW M12x1.75x30mm | CAPSCREW M12x1.75x30mm |
| 60. | ZW16X12000 | [2] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 61. | ZN16C12010 | [2] | NUT | KOB Superseded by part number: ZN18C12010 |
| 62. | 2436U425F3 | [1] | VALVE | KOB |
| 63. | 2436U424F3 | [1] | VALVE | KOB |
| 64. | ZS18C14065 | [2] | SCREW,Hex, M14 x 65mm | KOBM14x2.0x65mm |
| 65. | ZW26X14000 | [2] | WASHER | KOBID 14 x OD 24.5 x Th 3.5mm |
| 66. | 2418T10602 | [2] | TUBE | |
| 67. | ZK53R22000 | [2] | TUBE | |
| 68. | 2444R897D2 | [1] | HOSE | |
| 69. | 2444R897D3 | [1] | HOSE | |
| 70. | 2444R897D1 | [2] | HOSE | |
| 71. | ZK83P22000 | [2] | PLUG | KOB Superseded by part number: ZA83P22000 |
| 72. | ZK93N22000 | [2] | NUT | NUT |
| 73. | 2432T1799 | [1] | CLAMP | |
| 74. | 2416Z338 | [2] | SHEET,RUBBER, Serial Range: LE3401--LE4000 | |
| . . | 2416Z338 | [1] | SHEET,RUBBER, Start Serial: LE4001~ | |
| 75. | ZS16C10070 | [1] | CAPSCREW | CAPSCREW |
| 76. | ZH22Z08000 | [2] | HYD CONNECTOR | KOB1/2"PTx1/2"PFx48mm Long |
| 77. | R44T0224D1 | [1] | TEE | KOB |
| 78. | 2416Z350 | [1] | SHEET,RUBBER, Start Serial: LE4001~ | |
| 79. | ZG32B04000 | [1] | ELBOW | KOB, Start Serial: LE4237~ |
| 80. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
