神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (04-006) - HYDR LINES, UPP P/N 24100J4246F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
492 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4246F1 | [1] | INSTAL HYDR LINES, Serial Range: LE3401--LE4636 | |
| . . | 24100J4246F4 | [1] | 1NSTAL HYDR LINES, Start Serial: LE4637- | |
| 1. | 2418P394 | [1] | TUBE | |
| 2. | 2418P8395 | [1] | TUBE, Serial Range: LE3401--LE4636 | TUBE, Serial Range: LE3401--LE4636 |
| 3. | 2418P8396 | [1] | TUBE | TUBE |
| 4. | 2418P8397 | [1] | TUBE LE3401--, Serial Range: -LE4636 | TUBE LE3401--, Serial Range: -LE4636 |
| 5. | 2418T8094 | [1] | TUBE | TUBE |
| 6. | 2418T8095 | [1] | TUBE | TUBE |
| 7. | 2418P7671D3 | [1] | RIGID TUBE | KOB |
| 8. | 2418P7671D4 | [1] | TUBE | TUBE |
| 9. | ZX27N08040 | [6] | HOSE | KOB, Serial Range: LE3401--LE4636 |
| 10. | ZK24F18008 | [2] | HYD CONNECTOR | KOB |
| 11. | 2418P7675D2 | [2] | TUBE | TUBE |
| 12. | 2418P7675D1 | [2] | TUBE | TUBE |
| 13. | ZD12P01800 | [10] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 14. | ZC36X18011 | [3] | CLAMP | KOB |
| 15. | ZM11C10045 | [1] | SEMS-BOLT M10x1.50x45mm (Incls. Lockwasher) | SEMS-BOLT M10x1.50x45mm (Incls. Lockwasher) |
| 16. | ZS16C10090 | [1] | CAPSCREW | |
| 17. | ZN16C10008 | [1] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 18. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 19. | ZS23C08025 | [8] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 20. | ZW22K08000 | [8] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 21. | ZD11G02500 | [2] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOB |
| 22. | ZH21K08006 | [1] | HYD CONNECTOR | KOB |
| 23. | ZH51K08006 | [1] | TEE | KOB |
| 24. | ZH21K08008 | [1] | HYD CONNECTOR | KOB |
| 25. | ZX15K08060 | [1] | TUBE | KOBLE3401 -, Serial Range: -LE4636 |
| 26. | ZX15K08130 | [1] | FLEXIBLE HOSE | KOBLE3401-, Serial Range: -LE4636 |
| 30. | 2418P9822 | [1] | , Start Serial: LE4637- | |
| 31. | 2418P9823 | [1] | TUBE, Start Serial: LE4637- | |
| 34. | ZX15K08070 | [1] | FLEXIBLE HOSE | KOB, Start Serial: LE4S37~ |
| 35. | ZX15K08125 | [1] | TUBE, N2, Start Serial: LE4637- | |
| 36. | ZX27N08044 | [2] | HOSE, Start Serial: LE4637~- | |
