纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-33-00[00]) - CONTROL LINES, PROPEL (YT62H00006F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
499 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN30V00070F1 | [1] | VALVE | KOBAssembly, Pilot -- See Figure 08-26-00 Superseded by part number: YN30V00070F2 |
| A2. | 2420R349D082 | [2] | HYDRAULIC HOSE,6.35 mm ID x 820.00 mm | KOB Superseded by part number: 2420R349D085 |
| A3. | 2420R349D210 | [2] | FLEXIBLE HOSE | KOB2100mm Long (82-11/16 in) |
| A4. | 2420R349D240 | [2] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| A5. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(with filter) (Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of HH25X04004G2), ID 10.80 ± 0.18 x OD 15mm, Not Shown |
| A6. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH22X04000), SAE No. 4-1, Not Shown Superseded by part number: 72186131, 165202 |
| A7. | YF62H01001P1 | [4] | RUBBER BAND | KOB |
| A8. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| A9. | YX52S00013P1 | [2] | SENSOR | SMPressure (Low Pressure) (Incls. O-Ring ZD12P01100), Incls. Refs. A9-2 Superseded by part number: LC52S00019P1 |
| B1. | 2444Z2525 | [2] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) |
| B2. | ZH32X04000 | [4] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° (Incls. O-Ring 237-6004) |
| C1. | YN64H01337P1 | [1] | BLOCK | SMManifold |
| C2. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
