纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-43-01[01]) - SEAT, PNEUMATIC CUSHIONING HEATED - COMPONENTS (YN25M00068F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
793 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YN25M00068F1 | [1] | SEAT | KOBPneumatic Cushioning Heated Seat, YN25M00068F1 Superseded by part number: 87516076 |
| 2. | 87583756 | [1] | KIT | SMSeat Back Covering |
| 3. | 72116115 | [1] | KIT | LECseat Back |
| 4. | 87596492 | [1] | KIT | SMCushion Covering |
| 5. | 87596495 | [1] | CUSHION | SM |
| 6. | 87583759 | [1] | KIT | SMFrame |
| 7. | 87583764 | [1] | KIT | SMLumbar Superseded by part number: LC25M00001S007 |
| 8. | 71456224 | [1] | CABLE | LECRegulating |
| 9. | 87596954 | [1] | KIT | SMSeat Spring |
| 10. | 72116120 | [1] | KIT | SMHeater |
| 11. | 87596957 | [1] | KIT | SMGuide |
| 12. | 87596968 | [1] | KIT | SMSuspension |
| 13. | 71412020 | [1] | KIT | SMSpring Superseded by part number: 9969300 |
| 14. | 71412023 | [1] | KIT | SMStop Block Superseded by part number: 9969303 |
| 15. | 72116123 | [1] | PNEUMATIC VALVE | LEC |
| 16. | 87596972 | [1] | KIT | SMCompressor 24Volt |
| 17. | 87596986 | [1] | KIT | SMAir Pipes |
| 18. | 87596987 | [1] | KIT | SMStop Limiter |
| 20. | 72116127 | [1] | KIT | LECHandgrip |
| 21. | 72116128 | [1] | KIT | SMSuspension Cover |
| 22. | 71412018 | [1] | KIT | SMHeight Requlating System |
| 25. | 87379467 | [1] | KIT | SMHead Rest |
