神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-017) - PANEL ASSY, INST (FOR EXPORT) P/N 24100J6242F8 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
767 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6242F8 | [1] | PANEL ASSY, INST | |
| 6. | 2479Z214 | [1] | CIGARETTE LIGHTER | KOB |
| 7. | 24100P376F6 | [1] | LEVER & PIN ASSY | KOBLEVER ASSY. THROTTLE |
| 7-2. | B16P0275 | [1] | BRACKET | KOB |
| 7-3. | R16T0076 | [1] | WASHER | KOB |
| 7-4. | R16T0040 | [1] | WASHER | KOB Superseded by part number: 2418T12345, 77266155 |
| 7-5. | R16T0137D2 | [4] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 1.6mm |
| 7-6. | 2406T971 | [1] | GRIP | KOB |
| 7-7. | ZN11C12007 | [2] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12007 |
| 7-11. | 2406P2488 | [1] | LEVER | KOBLEVER |
| 8. | 2479T761 | [1] | MTG, SWITCH | |
| 10. | 2479R243F1 | [1] | FUSE BOX | KOB |
| 10-3. | 2479R243S1 | [7] | FUSE | KOB15 Amp |
| 11. | 4079Z22 | [1] | RELAY | KOB |
| 12. | R16T0063D3 | [2] | GROMMET | KOB |
| 13. | 2420R429D15 | [5] | GROMMET | KOB |
| 14. | 2420R429D4 | [1] | GROMMET | KOB |
| 15. | R16T0402D1 | [1] | CLAMP | KOB |
| 19. | 2479U303F1 | [1] | GAUGE | KOB |
| 20. | 2416T10921 | [1] | PLATE | PLATE |
| 21. | R79T0001 | [1] | SWITCH | KOB |
| 22. | 2479R676 | [1] | SWITCH | KOB |
| 21. | 2420R429D14 | [1] | GROMMET | KOB |
| 24. | ZS16C12020 | [2] | KEY | KOBM12x1.75x20mm Superseded by part number: ZS18C12020 |
| 25. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 26. | ZM11C10025 | [4] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 27. | ZM11C06014 | [16] | SCREW | KOB |
| 28. | ZS31C06012 | [11] | SCREW,Phillips Drive, Pan HD, M6 x 12mm | KOBM06x1.0x12mm |
| 29. | ZS31C05016 | [4] | BOLT,Phillips Drive, Pan HD, M5 x 16mm | KOBM05x0.8x16mm |
| 30. | ZW16X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 31. | 2418T5373C2 | [2] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 32. | ZW16X06000 | [16] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 33. | ZW16K05000 | [2] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 34. | ZW16K06000 | [8] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 35. | ZW26X06000 | [7] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 36. | ZW26X05000 | [2] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 37. | R06P0039D5F1 | [1] | FLEXIBLE CABLE | KOB |
| 37-4. | R06T0042D1 | [1] | END | KOB |
| 37-5. | B19T0175 | [1] | PIN | KOB |
| 37-6. | ZP15K01210 | [1] | LOCK PIN | KOB |
| 38. | 2430R157D14 | [1] | WIRE HARNESS | KOB |
| 49. | 2479U229 | [1] | RELAY | KOB |
| 50. | 2414T1999 | [1] | COVER | COVER |
| 54. | 2416T12884 | [1] | BRACKET | |
| 55. | ZM11C08016 | [3] | BOLT | KOBM08x1.25x16mm (Incls. Lockwasher) |
| 56. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 57. | 2416N2816 | [1] | BRACKET | BRACKET |
| 58. | ZS41C06025 | [4] | SCREW,M6 x 25mm | KOBM06x1.0x25mm |
| 60. | 2416P7309 | [1] | PANEL | PANEL |
| 4. | VI1814020031 | [1] | RESISTOR | KOBRESISTANSE, CONTROL, ISUZU ENGINE PARTS |
| 5. | VI9827102270 | [1] | SWITCH | KOBISUZU ENGINE PARTS Superseded by part number: VI8944024990 |
| 39. | VI1812510260 | [1] | CONTROL UNIT | KOBREGULATER, ISUZU ENGINE PARTS |
| 40. | VI9834200470 | [1] | SAFETY RELAY, ISUZU ENGINE PARTS | |
