纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-64-00[00]) - AIR CONDITIONER ASSEMBLY (YN20M00118F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
858 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN20M00107F3 | [1] | AIR CONDITIONER | SMAIR CONDITIONING Assembly Superseded by part number: YT20M00022F4 |
| 2. | LC20M01014D2 | [2] | HOSE,11mm ID x 360mm L | KOBID 11 x OD 15 x 360mm |
| 3. | 24100U1176S5 | [2] | CLAMP | KOB |
| 4. | YN50V01014P1 | [1] | CAB FILTER,124mm W x 491.5mm L | SMElement, Air-conditioner -- 478.5x114x31mm Superseded by part number: YN50V01014P1P |
