神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (05-008) - REDUCTION UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
477 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J3247F4 | [1] | MOTOR ASSY, Serial Range: LE3401--LE4699 | MOTOR ASSY, Serial Range: LE3401--LE4699 |
| . . | 24100J3247F5 | [1] | MOTOR ASSY, Start Serial: LE4700-- | MOTOR ASSY, Start Serial: LE4700-- |
| 2. | R45P0018D29 | [1] | SEAL,FLOATING | SEAL,FLOATING |
| 3. | ZS23C10035 | [16] | SCREW,Hex Socket Head, M10 x 35mm | KOBM10x1.50x35mm |
| 4. | 2404J130 | [1] | DRIVING SPROCKET | KOB |
| 5. | 2425R165D3 | [2] | BALL BEARING | KOB |
| 6. | 24100T187F1 | [1] | SHIM | KOB |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONRING,SNAP |
| 13. | 2418T4564 | [6] | WASHER | KOBTHRUST |
| 14. | 2414N1400 | [1] | COVER, Serial Range: LE3401--LE4148 | |
| . . | 2414N1400C1 | [1] | COVER, Start Serial: LE4149~ | COVER, Start Serial: LE4149~ |
| 15. | NSS | [3] | NOT SOLD SEPARAT | CONRING,SNAP |
| 17. | 2418T7062 | [1] | WASHER | |
| 19. | NSS | [1] | NOT SOLD SEPARAT | CONRING,SNAP |
| 21. | 2418T7063 | [1] | WASHER | |
| 22. | ZS23C08025 | [21] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 23. | 2418P6315 | [1] | PETAINER | |
| 24. | 24100T188F1 | [1] | SHIM ASSY | SHIM ASSY |
| 25. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 27. | 2401N390 | [1] | GEAR,INTERNAL | |
| 29. | 2401P518 | [3] | PINION | PINION |
| 30. | 2418T7895 | [6] | WASHER | KOBTHRUST |
| 31. | NSS | [3] | NOT SOLD SEPARAT | CONRING,SNAP |
| 32. | 2413N318F1 | [1] | SPIDER ASSY | SPIDER ASSY |
| 33. | 2401P517 | [1] | GEAR, SUN, Serial Range: LE3401---LE4699 | GEAR, SUN, Serial Range: LE3401---LE4699 |
| 35. | 2401P515 | [1] | SUN GEAR | KOB |
| 36. | 2413N319F2 | [1] | SPIDER | KOB |
| 37. | 2401P516 | [3] | PINION | KOB |
| 38. | 2441U313F4 | [1] | MOTOR | MOTOR |
| 39. | ZS73C10018 | [2] | SETSCREW | |
| 40. | 2401P858 | [1] | GEAR, SUN, Start Serial: LE4700- | GEAR, SUN, Start Serial: LE4700- |
