神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (09-008) - BUCKET ASSY, 0.35M³ Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
318 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2294F1 | [1] | BUCKET ASSY, Serial Range: LE3401--LE5469 | |
| . . | 24100N2294F2 | [1] | BUCKET ASSY, 0.35M3, Start Serial: LE5370- | BUCKET ASSY, 0.35M3, Start Serial: LE5370- |
| 1. | 2412J332F1 | [1] | BUCKET, Serial Range: LE3401--LE5369 | |
| 1-1. | 2412J332 | [1] | BUCKET | |
| 1-1P. | 2412P314D4 | [1] | EDGE, CUTTING | |
| 1-1O. | 2412N214 | [4] | ADAPTER | KOB |
| 1-2O. | 2405T873 | [4] | BUSHING | KOB |
| 2. | B12P0015F1 | [4] | TOOTH | KOB |
| 2-1. | B12P0015E1 | [1] | BUCKET TOOTH POINT | KOB |
| 2-2. | B12P0015E2 | [1] | PIN | KOB Superseded by part number: 2412Z162K |
| 2-3. | B12P0015E3 | [1] | LOCK PIN | KOB Superseded by part number: B12P0015E3MK |
| 3. | 2412N279D1 | [1] | BLADE | KOB |
| 4. | 2412N279D2 | [1] | BLADE | KOB |
| 5. | R16T0152D3 | [6] | WASHER | KOB |
| 6. | ZS13F20055 | [6] | SCREW | KOBM20x1.50x55mm |
| 7. | ZN13F20016 | [6] | NUT | KOBM20x1.50mm |
| 8. | 2445Z912 | [4] | O-RING | KOBID 90 ± 0.40 x OD 108mm |
| 9. | 2412J662F1 | [1] | BUCKET, Start Serial: LE5370- | |
| 9-1. | 2412J662 | [1] | BUCKET | |
| 9-1B. | 24J2P3J4D4 | [4] | EDGE, CUTTING | |
| 9-1P. | 2412N214 | [4] | ADAPTER | KOB |
| 9-18. | 2405T873 | [4] | BUSHING | KOB |
