纽荷兰零件查询(E80) - MIDI CRAWLER EXCAVATOR ASN LF04-02001 (03-007) - HYDRAULIC LINES, ARM 1.8M (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
130 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF43H00004F2 | [1] | HYD LINES, ARM 1.8M | |
| 2. | YT43H01013DA | [2] | HOSE | KOB |
| 3. | 24100P1006F1 | [2] | VALVE | KOBASSY, STOP Superseded by part number: 24100P1006F2 |
| 3-1. | 2436P230 | [1] | VALVE BODY | KOB |
| 3-2. | 2436T304 | [1] | VALVE | KOB |
| 3-3. | 2418T8945D1 | [1] | SPACER | KOB |
| 3-4. | ZR16X04000 | [1] | RING | KOBSNAP |
| 3-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBCAP |
| 3-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 3-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 3-8. | ZD75G04000 | [1] | BACK-UP RING | KOB |
| 3-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 3-10. | ZD85G03500 | [1] | RING | KOB |
| 3-11. | ZE82T04000 | [1] | PLUG | KOB |
| 4. | ZA23F22012 | [2] | HYD CONNECTOR | KOB |
| 5. | ZD12P02400 | [2] | O-RING | KOB |
| 6. | ZC26X22011 | [2] | CLAMP | KOB |
| 7. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBCAP |
| 8. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBCAP |
| 9. | ZW26X08000 | [8] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 10. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 11. | YT43H01004P1 | [2] | TUBE | KOB |
