神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (09-017) - GRAPPLE ASSY, FORK (DOUBLE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
951 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6202F1 | [1] | GRAPPLE ASSY,FORK | |
| 1. | 2412J689F1 | [1] | GRAPPLE | |
| 1-1. | 2412J689 | [1] | GRAPPLE | |
| 1-21. | 2405T1068 | [2] | BUSHING | |
| 2. | 2412J688 | [1] | GRAPPLE | |
| 3. | 2416N3244F1 | [1] | BRACKET | |
| 3-1. | 2416N3244 | [1] | BRACKET | |
| 3-15. | 2405T1068 | [2] | BUSHING | |
| 3-16. | 240511067 | [2] | BUSHING | |
| 4. | 2406N776F1 | [1] | LINK | |
| 4-1. | 2406N776 | [1] | LINK | |
| 4-13. | 2405T1067 | [2] | BUSHING | |
| 5. | 2406P2578D1F1 | [1] | LINK,IDLER | |
| 5-1. | 2406P2578D1 | [1] | LINK,IDLER | |
| 5-10. | 2405T1067 | [1] | BUSHING | |
| 6. | 2406P2578D2F1 | [1] | LINK,IDLER | |
| 6-1. | 2406P2578D2 | [1] | LINK,IDLER | |
| 6-10. | 2405T1067 | [1] | BUSHING | |
| 7. | 2406N777F1 | [1] | LINK,BUCKET | |
| 7-1. | 2406N777 | [1] | LINK,BUCKET | |
| 7-7. | 2405T1067 | [4] | BUSHING | |
| 8. | 2419P1565D5 | [1] | PIN | |
| 9. | 2419T3843 | [1] | PIN | |
| 10. | 2419T3845 | [2] | PIN | |
| 11. | 2419T3844 | [1] | PIN | |
| 12. | 2419T3842 | [1] | PIN | |
| 13. | 2419P1555D5 | [1] | PIN | |
| 14. | ZS13C12110 | [9] | SCREW | KOB Superseded by part number: ZS18C12110 |
| 15. | ZN17C12010 | [18] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 16. | ZG91S02000 | [9] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 17. | 2419P1555D4 | [2] | PIN | |
