神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (09-020) - BOOM ASSY, 3.0M P/N 24100J4222F1, F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
893 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4222F1 | [1] | BOOM ASSY | |
| . . | 24100J4222F2 | [1] | BOOM ASSY | |
| 1. | 2411J1672F1 | [1] | BOOM | |
| 1-20. | NSS | [2] | NOT SOLD SEPARAT | CONBUSHING |
| 2. | 2438U698F1 | [1] | CYLINDER, BOOM | CYLINDER, BOOM |
| 3. | 2438U699F1 | [1] | CYLINDER | |
| 4. | 2419P1410 | [1] | PIN | |
| . . | 2419P1545 | [1] | PIN | PIN |
| 5. | NSS | [2] | NOT SOLD SEPARAT | CON |
| . . | 2419P1553 | [2] | PIN | PIN |
| 6. | 2419P1397 | [1] | PIN | |
| . . | 2419P1549 | [1] | PIN | KOB |
| 7. | 2419P1411D2 | [1] | PIN | |
| . . | 2419P1559D1 | [1] | PIN | KOB |
| 8. | 2418P8326D1 | [1] | TUBE | |
| 9. | 2418P8326D2 | [1] | TUBE | |
| 10. | 2418P8327D1 | [1] | TUBE | |
| 11. | 2418P8327D2 | [1] | TUBE | |
| 12. | 2418T10011 | [1] | TUBE | |
| 13. | 2418T10010 | [1] | TUBE | |
| 14. | 2418T10062 | [1] | TUBE | TUBE |
| 15. | 2418T10066 | [1] | TUBE | TUBE |
| 16. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 17. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 18. | ZX27N08060 | [4] | HOSE | KOB |
| 19. | NSS | [4] | NOT SOLD SEPARAT | CON |
| 20. | ZC26X18011 | [8] | CLAMP | KOB Superseded by part number: ZC26M18011 |
| 21. | 2416T3204 | [2] | CLAMP | KOB |
| 22. | ZG91V02000 | [2] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| 23. | NSS | [4] | NOT SOLD SEPARAT | CON |
| 24. | ZG91S02000 | [3] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 25. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 26. | 2445R138D3 | [2] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 27. | NSS | [5] | NOT SOLD SEPARAT | CON |
| 28. | ZS16C08030 | [4] | CAPSCREW M08x1.25x30mm | CAPSCREW M08x1.25x30mm |
| 29. | ZS16C10040 | [10] | SCREW | KOBM10x1.50x40mm Superseded by part number: ZS18C10040 |
| 30. | ZS16C10050 | [2] | CAPSCREW M10x1.50x50mm | CAPSCREW M10x1.50x50mm |
| 31. | ZS16C12065 | [2] | SCREW | KOBM12x1.75x65mm Superseded by part number: ZS18C12065 |
| 32. | ZW22X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 33. | ZW22X10000 | [12] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 34. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 35. | ZN17C12010 | [10] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 36. | ZN16C12010 | [2] | NUT | KOB Superseded by part number: ZN18C12010 |
| 37. | ZN16C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 38. | 2416T9881 | [1] | SUPPORT | |
| 39. | 2416T9882 | [1] | PLATE | |
| 40. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 41. | 2418T10777 | [1] | TUBE | TUBE |
| 42. | P16T0442D19 | [2] | SHIM | |
