神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (10-001) - REWORK, INSTAL PLATE ASSY (FOR COLD REGION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
309 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1034F1 | [1] | PANEL ASSY,INST, Serial Range: LE3401-LE4402 | |
| . . | 24100P1034F6 | [1] | PANEL ASSY,INST, Start Serial: LE4403 | |
| 1. | 2430U144D3F1 | [1] | CABLE, CONTROL, Serial Range: LE3401-LE4402 | |
| 1-4. | R06T0042D1 | [1] | END | KOB |
| 1-5. | B19T0175 | [1] | PIN | KOB |
| 1-6. | ZP15K01210 | [1] | LOCK PIN | KOB |
| 4. | 2430U145D3 | [1] | CABLE, STOP | |
| 9. | 2430U144D3F2 | [1] | CABLE, CONTROL, Start Serial: LE4403 | |
| 9-4. | R06T0042D1 | [1] | END | KOB |
| 9-5. | B19T0175 | [1] | PIN | KOB |
| 9-6. | ZP15K01210 | [1] | LOCK PIN | KOB |
