凯斯零件查询(LB424R) - BALER (9/12-) (88.070.016[02]) - DIA KIT: ROLLER BALE CHUTE - D137 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
781 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47861062
|
[1] |
DIA KIT, HARVESTER
|
ATT
Incl 2 - 8
|
| 2. |
84300618
|
[1] |
HYDRAULIC CYLINDER
|
ZED
|
| 3. |
47931704
|
[1] |
ROLLER
|
ZED
|
| 4. |
412109
|
[1] |
PIN
|
ZED
|
| 5. |
378246
|
[3] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 6. |
84814924
|
[2] |
WASHER,16.3mm ID x 31.5mm OD x 1.25mm Thk
|
ZED
|
| 7. |
130007
|
[3] |
COTTER PIN,M4 x 25
|
NH
Superseded by part number: 83903970
|
| 8. |
47931819
|
[1] |
PIN
|
ZED
|
