凯斯零件查询(LB424R) - BALER (9/12-) (88.070.018[02]) - DIA KIT: PARTIAL BALE EJECT - D137 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
313 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47866687
|
[1] |
DIA KIT, HARVESTER
|
ATT
Incl 2 - 9
|
| 2. |
9813512
|
[2] |
HYD CONNECTOR
|
ZED
Superseded by part number: 89813512
|
| 3. |
395019
|
[2] |
HYD CONNECTOR,M18 x 1.5 ORB x M16 x 1.5 ORB
|
PA
|
| 4. |
86566990
|
[4] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 5. |
120056
|
[1] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
|
| 6. |
47794063
|
[1] |
VALVE
|
ZED
|
| 7. |
9706748
|
[1] |
CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type
|
NH
|
| 8. |
47371204
|
[2] |
HYDRAULIC HOSE,7.92mm ID x 1450mm L, SAE 100R16
|
ZED
|
| 9. |
84542395
|
[1] |
HYD TUBE
|
ZED
|
| . . |
87479616
|
[1] |
DECAL
|
ZED
|
