| . . | 24100J6145F1 | [1] | TANK ASSY | |
| 1. | 2427J1294 | [1] | TANK | |
| 2. | R36T0006 | [1] | STRAINER ELEMENT | KOB |
| 3. | 2446R310 | [1] | FILLER CAP | KOB |
| 4. | 2420Z1030 | [1] | KEY | KOB Superseded by part number: YN50S01010P1 |
| 5. | 2436R241F1 | [1] | COCK | KOB Superseded by part number: LC20P01028P1 |
| 5-2. | B14N0094E14 | [1] | PACKING | KOB |
| 6. | ZE82T08000 | [2] | PLUG | KOB1/2" PT |
| 7. | 2418T9962 | [1] | PACKING | KOBID 41 x OD 68 x Th 2.0mm |
| 8. | 2489U168F1 | [1] | SENDER UNIT | KOBFUEL |
| 9. | ZS31C05010 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 10mm | KOBM05x0.8x10mm |
| 10. | ZW26X05000 | [5] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 11. | ZS13C16035 | [3] | SCREW | KOBM16x2.0x35mm |
| 12. | ZW22X16000 | [3] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 13. | R16T0152D2 | [3] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm |
| 14. | 2414T2042 | [1] | COVER | COVER |
| 15. | 2489R296F1 | [1] | LEVEL GAUGE | KOBGAUGE, LEVEL |
| 15-1. | 2489R296S1 | [1] | VACUUM GAUGE | KOB |
| 15-2. | 2489R174S3 | [2] | BOLT | KOBSpecial -- M10x1.50x40mm Long |
| 15-3. | 2489R174S2 | [2] | BLOCK | KOBGAUGE, LEVEL |
| 15-4. | ZD11P01800 | [4] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 15-5. | ZD11P01000 | [4] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 15-6. | 2489R174S7 | [1] | FLOAT | KOB |
| 16. | 2420Z980D1 | [1] | BOLT | KOB Superseded by part number: 1096750860 |
| 17. | 2444Z2228D1 | [1] | PIPE | KOBJOINT Superseded by part number: VI5154112231 |
| 18. | 2420Z975D2 | [2] | GASKET | KOB Superseded by part number: VI1096300850 |
| 19. | 2446R147 | [1] | ELEMENT | KOBRETURN Superseded by part number: 24046Z15P |
| 20. | 2446U119S3 | [1] | VALVE | KOBBY-PASS |
| 21. | 2446U119S2 | [1] | SPRING | KOB |
| 22. | 2418T4572D1 | [1] | FLANGE | KOB |
| 23. | ZD11P13000 | [1] | O-RING | KOBID 129.6 ± 1.05 x OD 140mm |
| 24. | ZS18C12025 | [8] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 25. | ZW26X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 26. | ZD11G16500 | [1] | O-RING,164.30mm ID x 175.70mm OD x 5.70mm | KOBID 164.30 ± 1.30 x OD 175.7mm |
| 27. | 2418P9988 | [1] | FLANGE | KOB |
| 28. | 2446U228F1 | [1] | BREATHER | KOB |
| 28-1. | 2446U228S1 | [1] | CASE | KOBASSY |
| 28-2. | 2446U228S2 | [1] | STRAINER ELEMENT | KOB Superseded by part number: 2446R133 |
| 28-3. | 2446U228S3 | [1] | GASKET | KOBPACKING |
| 28-4. | 2446U228S4 | [3] | SCREW | KOB |
| 28-5. | ZD11P03200 | [1] | O-RING | KOB |
| 28-6. | 2446U228S6 | [1] | VALVE | KOBASSY |
| 28-7. | 2446U228S7 | [1] | COVER | KOB |
| 28-8. | 2446U228S8 | [1] | ELEMENT | KOB |
| 28-9. | 2446U228S9 | [1] | COVER | KOB |
| 28-10. | 2446U228S10 | [1] | SCREW | KOB |
| 28-11. | 2446U228S11 | [1] | BOX SPANNER | KOB |
| 28-12. | 2446U228S12 | [1] | LABEL | KOB |
| 29. | 2446R307F2 | [1] | STRAINER ELEMENT | KOBSUCTION |
| 29-1. | 2446R307S1 | [1] | STRAINER ASSY. | KOB Superseded by part number: YN50V00002S001 |
| 29-3. | 2446R110S2 | [1] | HOLDER | KOB |
| 29-4. | ZN11C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 29-5. | 2446R110S6 | [1] | SPRING | KOB |
| 29-6. | 45Z91D6 | [1] | O-RING | KOBID 97.79 ± 0.38 OD 108.45mm |
| 29-7. | 2446R110S5 | [1] | SCREW | KOB |
| 30. | ZH31M08008 | [1] | ELBOW | KOB |
| 31. | 2444Z2322 | [1] | TEE | KOB |
| 32. | ZS13C08018 | [4] | SCREW | KOBM08x1.25x18mm Superseded by part number: ZS18C08020 |
| 33. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 34. | ZW11X08000 | [4] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 35. | ZA33F22008 | [1] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| 36. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 37. | 2446U215F1 | [1] | FILTER, DRAIN | FILTER, DRAIN |
| 37-1. | 2446U215S01 | [1] | CONTAINER | KOB |
| 37-2. | 2446U175S2 | [1] | VALVE | KOB |
| 37-3. | 2446U175S3 | [1] | SPARE PART | HITCARTRIDGE Superseded by part number: 2446U215S5P |
| 38. | 2489R293F1 | [1] | LEVEL GAUGE | KOB Superseded by part number: YN58S00009F1 |
| 38-1. | 2489R173S1 | [1] | GAUGE | KOB |
| 38-2. | 2489R174S3 | [2] | BOLT | KOBSpecial -- M10x1.50x40mm Long |
| 38-3. | 2489R174S2 | [2] | BLOCK | KOBGAUGE, LEVEL |
| 38-4. | ZD11P01800 | [4] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 38-5. | ZD11P01000 | [4] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 39. | 2427T826 | [1] | PLATE | KOB |
| 40. | ZA93N22000 | [1] | TUBE NUT | KOB |
| 41. | ZA93S22000 | [1] | RING | KOBSLEEVE |
| 42. | 2418T17283D1 | [3] | SPACER | KOB |
| 43. | ZA82P22000 | [1] | PLUG | KOB |
| . . | 24046Z15 | [1] | ELEMENT | KOBKIT, CONSISTS OF REF 19 & 23 Superseded by part number: 24046Z15P |
