神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (01-001) - INSTAL CAB, P/N 24100N3063F1, F2, F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
205 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N3063F1 | [1] | INSTAL, CAB, Serial Range: LE5701-LE5703 | |
| . . | 24100N3063F3 | [1] | INSTAL, CAB, Start Serial: LE5704 | |
| 1. | 24100J6107F9 | [1] | CAB ASSY, SEE FIGURE 01-003, Serial Range: LE5701-LE5703 | |
| 2. | ZS18C12070 | [6] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
| 3. | ZW26X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 4. | ZW16H12000 | [8] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 5. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 7. | 24100J6107F11 | [1] | CAB ASSY, SEE FIGURE 01-003, Start Serial: LE5704 | |
| . . | 24100N3063F2 | [1] | INSTAL, CAB | |
| 6. | 24100J6107F10 | [1] | CAB ASSY, SEE FIGURE 01-005 | |
