现代零件查询R360LC-7A BUCKET(1.62M3 SAE HEAPED, HEAVY DUTY)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
481 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
61NA-30601
|
[1] |
BUCKET ASSY
|
|
| . |
61NA-30601BG
|
[1] |
BUCKET ASSY
|
|
| . |
61NA-30602BG
|
[1] |
BUCKET ASSY
|
|
| 1. |
61NA-36011
|
[1] |
BUCKET WA
|
|
| 1. |
61NA-36011BG
|
[1] |
BUCKET WA
|
|
| 1. |
61NA-36012BG
|
[1] |
BUCKET WA
|
|
| 1-1. |
61NA-31320
|
[5] |
ADAPTER-TOOTH
|
|
| 1-1. |
61QA-31320
|
[5] |
ADAPTER-TOOTH
|
|
| 2. |
61NA-31310
|
[5] |
POINT-TOOTH
|
|
| 2. |
61NA-31310BG
|
[5] |
POINT-TOOTH
|
|
| 2. |
61QA-31310
|
[5] |
POINT-TOOTH
|
|
| 3. |
61E7-0105
|
[5] |
PIN-TOOTH
|
|
| 4. |
61E5-1126
|
[1] |
BUSHING
|
|
| 5. |
61E5-3136
|
[1] |
COVER PLATE
|
|
| 6. |
61E5-3141
|
[6] |
SHIM(1.0T)
|
|
| 7. |
S017-160506
|
[3] |
BOLT-HEX
|
|
| 8. |
S441-160006
|
[3] |
WASHER-HARDENED
|
|
| 9. |
61EH-11150
|
[5] |
LOCK WASHER
|
|
