| 1. |
84532852
|
[1] |
HINGE
|
ZED
|
| 2. |
84532854
|
[1] |
HINGE
|
ZED
|
| 3. |
47360686
|
[1] |
SUPPORT
|
ZED
|
| 4. |
47360685
|
[1] |
SUPPORT
|
ZED
|
| 5. |
47360690
|
[2] |
BUSHING,15mm ID x 23mm OD x 71.5mm L
|
ZED
|
| 6. |
47360694
|
[2] |
BUSHING,10.5mm ID x 30mm OD x 80.9mm L
|
ZED
|
| 7. |
84557721
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C084
|
| 7. |
47485660
|
[1] |
SUPPORT
|
ZED
, Start Serial: D085
|
| 7. |
84539326
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C084 Superseded by part number: 47485655
|
| 7. |
47485655
|
[1] |
SUPPORT
|
ZED
, Start Serial: D085
|
| 8. |
84539323
|
[2] |
BUSHING,26mm ID x 55mm OD x 50mm L
|
ZED
|
| 9. |
47360530
|
[1] |
TUBE
|
ZED
|
| 10. |
9839087
|
[2] |
NYLON BEARING,25.5mm ID x 50mm OD x 30mm Thk
|
ZED
|
| 11. |
84557725
|
[1] |
TRAY
|
ZED
, Serial Range: -C084 Superseded by part number: 47485670
|
| 11. |
47485670
|
[1] |
TUBE
|
ZED
, Start Serial: D085
|
| 11. |
84539312
|
[1] |
TRAY
|
ZED
, Serial Range: -C084 Superseded by part number: 47485664
|
| 11. |
47485664
|
[1] |
TUBE
|
ZED
, Start Serial: D085
|
| 12. |
47360693
|
[1] |
ANGLE
|
ZED
|
| 13. |
47360680
|
[1] |
HANDLE
|
ZED
,, Serial Range: -C047
|
| 13. |
47442631
|
[1] |
HANDLE
|
ZED
,, Start Serial: D048
|
| 14. |
84511802
|
[1] |
PLATE
|
ZED
|
| 15. |
47373610
|
[1] |
GAS STRUT
|
ZED
|
| 16. |
84557382
|
[1] |
GAS STRUT
|
ZED
|
| 17. |
86625263
|
[10] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 18. |
43127
|
[12] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 19. |
322358
|
[16] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 20. |
9706690
|
[14] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 21. |
120075
|
[2] |
BOLT,M10 x 1.5 x 106.58mm, Cl 8.8
|
NH
|
| 22. |
140045
|
[7] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 23. |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 24. |
120104
|
[3] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 25. |
84556531
|
[2] |
NUT
|
ZED
|
| 26. |
370002
|
[5] |
CIRCLIP,M25, External
|
NH
|
| 27. |
11067274
|
[3] |
SNAP RING,M24, Ext
|
JES
|
| 28. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
L= 0.236M Superseded by part number: 47560081, 47560080
|
| 29. |
14497401
|
[2] |
WASHER,28mm ID x 50mm OD x 4mm Thk
|
IMO
,, Serial Range: -C047
|
| 29. |
140229
|
[1] |
WASHER
|
ZED
,, Start Serial: D048
|
| 30. |
83904166
|
[1] |
WASHER,10.5mm ID x 30mm OD x 4mm Thk
|
BAS
,, Serial Range: -C047
|
| 30. |
12646204
|
[1] |
WASHER,8.15mm ID x 35mm OD x 3mm Thk
|
TTF
,, Start Serial: D048
|
| 31. |
86625006
|
[1] |
BOLT,Hex, M8 x 1 x 16mm, Cl 8.8, Full Thd
|
IMO
|
| 32. |
120100
|
[2] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 33. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 34. |
9706755
|
[2] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 35. |
332809
|
[1] |
HANDLE GRIP
|
ZED
|
| 36. |
84607524
|
[1] |
BUSHING,10.5mm ID x 16mm OD x 17.5mm L
|
ZED
, Serial Range: -C144
|
| 37. |
84453022
|
[1] |
BUTTON
|
ZED
, Serial Range: -C144
|
| 37. |
47925976
|
[1] |
KNOB
|
ZED
, Start Serial: D145
|
| 38. |
43140
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 39. |
84534242
|
[1] |
PLATE
|
ZED
|
| 40. |
86511324
|
[5] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 41. |
9512667
|
[1] |
COTTER PIN,M2 x 20mm OAL
|
CUR
, Serial Range: -C084
|
| 41. |
130003
|
[1] |
COTTER PIN,3mm OD x 30mm OAL
|
ZED
, Start Serial: D085
|
| 42. |
87541982
|
[2] |
INSULATOR BLOCK
|
ZED
|
| 43. |
87542959
|
[2] |
WASHER,6.15mm ID x 30mm OD x 1.5mm Thk
|
BN
|
| 44. |
412650
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 22mm OD x 1.4mm Thk
|
ZED
|
| 45. |
84807411
|
[2] |
THIN NUT,Thin, M10 x 1.5, Cl 04
|
ZED
Superseded by part number: 57039
|
| 46. |
43128
|
[2] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 47. |
378248
|
[2] |
WASHER,25mm ID x 50mm OD x 4mm Thk
|
ZED
|
| 48. |
12647004
|
[10] |
WASHER,8.15mm ID x 25mm OD x 2.5mm Thk
|
IMO
|
| 49. |
47360535
|
[1] |
TUBE
|
ZED
|
