| 1. |
84346533
|
[1] |
SHIM
|
ZED
|
| 2. |
47361014
|
[1] |
ROLLER BEARING,130mm ID x 200mm OD x 45mm W
|
ZED
, Serial Range: -C144
|
| 2. |
47706751
|
[1] |
SPHERICAL BEARING
|
ZED
, Start Serial: D145
|
| 3. |
84346516
|
[1] |
GEAR
|
ZED
, Serial Range: -C144
|
| 3. |
47706730
|
[1] |
GEAR
|
ZED
, Start Serial: D145
|
| 4. |
84346540
|
[1] |
GEAR
|
ZED
Incl 24, 25, Serial Range: -C144
|
| 4. |
47706758
|
[1] |
GEAR
|
ZED
Incl 24, 25, Start Serial: D145
|
| 5. |
47361013
|
[1] |
ROLLER BEARING,120mm ID x 180mm OD x 38mm W
|
ZED
, Serial Range: -C144
|
| 6. |
84074480
|
[1] |
O-RING
|
ZED
, Serial Range: -C144
|
| 6. |
84346539
|
[1] |
O-RING,3.53mm Thk x 209.1mm ID
|
ZED
, Start Serial: D145
|
| 7. |
84346527
|
[20] |
SCREW,M12 x 45mm, Cl 12.9
|
ZED
, Serial Range: -C144
|
| 7. |
87022684
|
[20] |
BOLT,Hex, M12 x 45mm, Cl 10.9
|
GI
, Start Serial: D145
|
| 8. |
84074465
|
[20] |
WASHER
|
ZED
, Serial Range: -C144
|
| 8. |
412123
|
[20] |
LOCK WASHER,13.1mm ID x 21.1mm OD x 2.55mm Thk
|
NH
, Start Serial: D145
|
| 9. |
47360999
|
[1] |
COVER
|
ZED
, Serial Range: -C144
|
| 9. |
47706739
|
[1] |
COVER
|
ZED
, Start Serial: D145
|
| 11. |
84346531
|
[1] |
SHIM
|
ZED
, Serial Range: -C144
|
| 12. |
47361003
|
[1] |
COVER
|
ZED
, Serial Range: -C144
|
| 13. |
80681
|
[6] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 14. |
43127
|
[6] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 15. |
84074442
|
[1] |
COVER
|
ZED
|
| 16. |
84074453
|
[1] |
GASKET,0.2mm Thk
|
ZED
|
| 17. |
536079
|
[1] |
OIL SEAL
|
ZED
|
| 18. |
86566099
|
[2] |
HEX SOC SCREW,M8 x 16mm, Cl 12.9
|
ZED
Superseded by part number: 14306221
|
| 19. |
84074464
|
[1] |
RING NUT
|
ZED
|
| 20. |
26800020
|
[1] |
TAPERED BEARING,70mm ID x 125mm OD x 26.25mm W
|
ZED
|
| 21. |
84074469
|
[1] |
SHIM KIT
|
ZED
|
| 22. |
9839403
|
[1] |
TAPERED BEARING,75mm ID x 160mm OD x 58mm W
|
ZED
|
| 23. |
47361011
|
[1] |
RING NUT
|
ZED
, Serial Range: -C120
|
| 23. |
47706673
|
[1] |
RING
|
ZED
, Start Serial: D121
|
| 24. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Gear Incl in 4
|
| 26. |
47609984
|
[2] |
BOLT,Hex, M8 x 30mm, Cl 12.9
|
ZED
, Start Serial: D121
|
