| . . | 24100N4007F2 | [1] | TOOL ASSY | |
| 1. | ZT12A36000 | [2] | SEAT BACK | KOBSpanner, 36mm |
| 2. | ZT12A32000 | [1] | SEAT BACK | KOB |
| 3. | ZT12A27000 | [1] | HEATER | KOB27mm |
| 4. | ZT12A19000 | [1] | GEAR | KOBSpanner, 19mm |
| 5. | ZT12A17000 | [1] | PLUG | KOBSpanner, 17mm |
| 6. | ZT12A10000 | [1] | PLUG | KOBSpanner, 10mm |
| 7. | 2421Z294 | [1] | BLOCK DRIVER | KOBDRIVER Screw, 165mm Long |
| 8. | ZT31B13250 | [1] | HANDLE | KOB |
| 9. | ZT31D13150 | [1] | BAR | KOB |
| 10. | ZT31A17000 | [1] | SOCKET | KOB |
| 11. | ZT31A19000 | [1] | SOCKET | KOB |
| 12. | ZT31A22000 | [1] | SOCKET | KOB |
| 13. | ZT31A24000 | [1] | SOCKET | KOB |
| 15. | ZT22A06000 | [1] | KEY, SCREW 06mm | KEY, SCREW 06mm |
| 16. | ZT22A08000 | [1] | KEY | KOBScrew -- 08mm |
| 17. | ZT22A14000 | [1] | KEY | KOB14mm |
| 18. | 2421R145 | [1] | GREASE GUN | KOB Superseded by part number: YT01T01009F1 |
| 19. | ZT12D20000 | [1] | WRENCH, ADJUST 24mm Maximum | WRENCH, ADJUST 24mm Maximum |
| 20. | 2421T8 | [1] | TIGHTENER | KOB |
| 21. | ZT71A15000 | [1] | HAMMER | KOB |
| 22. | 4027R1 | [1] | COMPLETE TOOL BOX | KOB |
| 23. | 2421Z210 | [1] | HOLDER | KOB |
| 24. | ZT51A15000 | [1] | PLIERS | KOB |
| 25. | 2421R127 | [1] | SPECIAL WRENCH | KOB |
| 25. | 2421R170 | [1] | GENERAL TOOL | KOB Superseded by part number: YW01T01014P1 |
| 26. | ZT22A10000 | [1] | KEY | KOB10mm |
| 27. | 2444Z2703 | [1] | HOSE | KOB |
| 36. | 2421Z243 | [1] | KOBELCO CAP | |
| 39. | B16T0442D19 | [3] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOBID 62 x OD 100 x Th 1.6mm |
| 40. | B16T0442D20 | [1] | SHIM,100mm OD x 62mm ID x 2.3mm Thk | KOBID 62 x OD 100 x Th 2.3mm |
| 41. | B16T0442D21 | [1] | SHIM,57mm ID x 90mm OD x 1.6mm Thk | KOBID 57 x OD 90 x Th 1.6mm Superseded by part number: 2420P963D4 |
| 42. | B16T0442D22 | [1] | SHIM,90mm OD x 57mm ID x 2.3mm Thk | KOBID 57 x OD 90 x Th 2.3mm |
| 43. | B16T0442D23 | [1] | SHIM,80mm OD x 52mm ID x 1.6mm Thk | KOBID 52 x OD 80 x Th 1.6mm |
| 44. | B16T0442D24 | [1] | SHIM,80mm OD x 52mm ID x 2.3mm Thk | KOBID 52 x OD 80 x Th 2.3mm |
| 45. | B16T0442D25 | [3] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOBID 52 x OD 80 x Th 1.2mm |
| 46. | B16T0442D26 | [1] | SHIM,90mm OD x 57mm ID x 1.2mm Thk | KOBID 57 x OD 90 x Th 1.2mm |
| 47. | B16T0442D27 | [3] | SHIM,62mm ID x 100mm OD x 1.2mm Thk | KOBID 62 x OD 100 x Th 1.2mm |
| 48. | B16T0442D30 | [3] | SHIM,100mm OD x 62mm ID x 2.0mm Thk | KOBID 62 x OD 100 x Th 2.0mm |
| 49. | B16T0442D31 | [1] | SHIM ID 57 x OD 90 x Th 2.0mm | SHIM ID 57 x OD 90 x Th 2.0mm |
| 50. | B16T0442D32 | [1] | SHIM,80mm OD x 52mm ID x 2.0mm Thk | KOBID 52 x OD 80 x Th 2.0mm |
