| . . | 24100J6393F1 | [1] | CONTROL ASSY, Serial Range: LE5701-LE5898 | |
| . . | 24100J6393F2 | [1] | CONTROL ASSY, Start Serial: LE5899 | |
| 1. | 24100N3050F1 | [1] | LEVER ASSY,CONTROL,P.201-01, Serial Range: LE5701-LE5970 | |
| 2. | 2418T12644 | [2] | PLATE, (89) | |
| 3. | 2406T1672 | [2] | YOKE | KOB Superseded by part number: 2406T2278 |
| 4. | 2419T3784D1 | [10] | PIN | KOB |
| 5. | ZW16X12000 | [10] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 6. | 2419R9D4 | [10] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 7. | 2416T13247 | [1] | BRACKET | |
| 8. | 2420Z681 | [7] | ROD | KOB |
| 9. | 2406R237D1 | [1] | BALL,LEVER | BALL,LEVER |
| 10. | 2406R237D2 | [1] | LEVER | KOB Superseded by part number: 2406R237D3 |
| 11. | 2406P2623D1 | [1] | LEVER ASSY, Serial Range: LE5701-LE5898 | |
| 12. | 2406P2623D2 | [1] | LEVER ASSY, Serial Range: LE5701-LE5898 | |
| 13. | 2414R233 | [2] | BOOT | KOB |
| 14. | 2416N3297 | [1] | STAND,CONTROL | |
| 14-8. | 2405R61D6 | [1] | BUSHING | BUSHING |
| 14-10. | 2405R61D2 | [1] | BUSHING,12mm ID x 14mm OD x 15mm L | KOB, Serial Range: LE5701-LE5826 |
| 14-10. | 2405R61D10 | [1] | BUSHING, Start Serial: LE5827 | BUSHING, Start Serial: LE5827 |
| 15. | 2416N3296 | [1] | STAND,CONTROL | |
| 15-9. | 2405R61D6 | [1] | BUSHING | BUSHING |
| 15-11. | 2405R61D2 | [1] | BUSHING,12mm ID x 14mm OD x 15mm L | KOB, Serial Range: LE5701-LE5826 |
| 15-11. | 2405R61D10 | [1] | BUSHING, Start Serial: LE5827 | BUSHING, Start Serial: LE5827 |
| 16. | 2414T2733D1 | [1] | COVER | |
| 17. | 2414T2733D2 | [1] | COVER | |
| 18. | 2419T3805 | [2] | PIN | PIN |
| 18-2. | 2405R61D5 | [1] | BUSHING,14mm ID x 16mm OD x 15mm L | KOB |
| 19. | 2418T12409 | [2] | WASHER | KOB |
| 20. | ZR16X01600 | [2] | SNAP RING | KOBRetaining -- ID 14.7 x OD 16 x Th 1.0mm |
| 21. | 2418T12410D1 | [2] | SHIM | KOB |
| 22. | 2418T12410D2 | [2] | SHIM | SHIM |
| 23. | 2419T3109 | [2] | PIN | PIN |
| 24. | 2406P3887D1 | [1] | LEVER | LEVER |
| 25. | 2406P2621 | [1] | LEVER, Serial Range: LE5701-LE6030 | |
| 25. | 2406P3900 | [1] | LEVER, Start Serial: LE6031 | |
| 26. | 2417T515 | [2] | SPRING | KOB |
| 27. | ZP26D05020 | [2] | PIN | KOBSpring |
| 28. | 2414Z270D3 | [2] | CAP | CAP |
| 29. | 2406Z313 | [4] | END | KOB |
| 30. | 2406T1730D3 | [4] | ROD | |
| 31. | 2406Z254 | [4] | ROD | KOB |
| 32. | 2406T2358 | [2] | LINK | |
| 33. | 2406T2359 | [2] | LINK | |
| 34. | 2406Z255 | [8] | ROD | KOB |
| 35. | 2406Z293 | [4] | ROD | KOB |
| 36. | 2420T4514 | [2] | STUD | |
| 37. | 2420T4065 | [8] | STUD | KOB |
| 38. | 2406R203D3 | [2] | CABLE | KOB Superseded by part number: 2406R203D6 |
| 39. | 2416T13148 | [1] | BOSS | |
| 40. | 2416T13147 | [1] | BRACKET | |
| 41. | 2416T13144 | [1] | BRACKET | |
| 42. | 2406T1188C2 | [4] | EYE BOLT | EYE BOLT |
| 43. | 2406T1650D1 | [8] | LINK | LINK |
| 44. | 2406P2570 | [1] | LINK | LINK |
| 44-3. | 2405R61D4 | [2] | BUSHING | KOB |
| 45. | 2406T2295 | [2] | LINK | LINK |
| 46. | 2419P1667 | [1] | SHAFT | |
| 47. | ZP26D05028 | [2] | PIN,5mm OD x 28mm L, Slotted | KOBSpring |
| 48. | 2425Z509 | [2] | BLOCK, BEARING | BLOCK, BEARING |
| 49. | 2406R236D2 | [1] | CABLE | KOB, Serial Range: LE5701-LE5856 |
| 50. | 2414P4027 | [1] | COVER | |
| 51. | 2419T4634 | [1] | PIN | KOBPIN |
| 51-3. | 2414Z270D2 | [1] | CAP | KOB |
| 52. | 2416T13333 | [1] | BRACKET | |
| 53. | 2479Z955 | [2] | LIMIT SWITCH | KOB Superseded by part number: 2479Z700 |
| 54. | 2420Z1042 | [1] | GROMMET | KOB Superseded by part number: 2420Z1301 |
| 55. | ZS18C14040 | [4] | SCREW,Hex, M14 x 40mm | KOBM14x2.0x40mm |
| 56. | ZS13C12030 | [4] | CAPSCREW | KOBSCREW M12x1.75x30mm, Serial Range: LE5701-LE5856 Superseded by part number: ZS18C12030 |
| 57. | ZS18C10035 | [4] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 58. | ZS18C10030 | [10] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 59. | ZS18C10025 | [6] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 60. | ZS18C08012 | [4] | SCREW,Hex, M8 x 12mm | KOBM08x1.25x12mm |
| 61. | ZS31C05010 | [10] | BOLT,Phillips Drive, Pan HD, M5 x 10mm | KOBM05x0.8x10mm |
| 62. | ZN17C14011 | [8] | NUT | |
| 63. | ZN17F12007 | [2] | NUT | KOB |
| 64. | ZN17C10008 | [8] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 65. | ZN17C08007 | [15] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 66. | ZW16X10000 | [10] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 67. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 68. | ZW26X14000 | [4] | WASHER | KOBID 14 x OD 24.5 x Th 3.5mm |
| 69. | ZW22X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 70. | ZW26X10000 | [26] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 71. | ZW26X08000 | [8] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 72. | ZW26X05000 | [2] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 73. | 2406P2624 | [1] | LEVER | |
| 75. | ZW11P05000 | [8] | WASHER | KOB Superseded by part number: ZW16P05000 |
| 78. | 2406P3887D2 | [1] | LEVER | LEVER |
| 79. | 2406R203D4 | [4] | CABLE | KOB |
| 80. | 2419P1721D1 | [1] | PIN ASSY, Start Serial: LE5899 | |
| 81. | 2419P1721D2 | [1] | PIN ASSY, Start Serial: LE5899 | |
| 82. | 2406P3960 | [2] | LEVER, Start Serial: LE5899 | LEVER, Start Serial: LE5899 |
| 83. | ZN17C12010 | [2] | NUT | KOBM12x1.75mm, Start Serial: LE5899 Superseded by part number: ZN18C12010 |
| 84. | 2406R203D2 | [1] | CABLE | KOB, Start Serial: LE5857 |
| 85. | 2406R203D7 | [1] | CABLE, CONTROL, Start Serial: LE5857 | CABLE, CONTROL, Start Serial: LE5857 |
| 86. | 2416T13409 | [1] | BRACKET, Start Serial: LE5857 | |
| 87. | 2406T2366 | [2] | LINK, Start Serial: LE5857 | |
| 88. | 2406T2367 | [2] | LINK, Start Serial: LE5857 | |
| 89. | 24100N3050F2 | [1] | LEVER ASSY,CONTROL,P.201-01, Start Serial: LE5971 | |
