| . . | 24100J6387F2 | [1] | REMOTE-CONTROL ASSV | |
| 1. | ZA23B22000 | [1] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| 2. | 2418T17352 | [1] | TUBE | |
| 3. | R18P0168D29 | [1] | FLEXIBLE HOSE | KOB |
| 4. | ZC15X03300 | [4] | CLIP | KOB |
| 5. | 2418T17353 | [1] | TUBE | |
| 6. | ZA33F22012 | [1] | ELBOW | KOB |
| 7. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 8. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 9. | 2420R537D030 | [1] | HOSE,9.53mm ID x 300mm L | KOB |
| 10. | ZH22X06000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) (PF3/8) |
| 11. | 2446U230F1 | [1] | FILTER ASSY | KOB |
| 12. | ZA33F10006 | [1] | ELBOW | KOB |
| 13. | ZD12P01400 | [3] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 14. | ZH31M08004 | [2] | ELBOW | KOB |
| 15. | 2420T4494 | [1] | PLUG | KOB |
| 16. | ZD12P01600 | [1] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 17. | 2418T17355D1 | [2] | TUBE | |
| 18. | ZE72X06000 | [2] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 19. | 2436R680F2 | [1] | VALVE PRESSURE RELIE | KOB |
| 20. | ZA23F10006 | [2] | HYD CONNECTOR | KOB |
| 21. | ZA23F10004 | [5] | HYD CONNECTOR | KOB1/4" PF x M16x1.50 x 33mm Long |
| 22. | ZD12P01100 | [6] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 23. | 2436R688F1 | [1] | SOLENOID VALVE | KOB |
| 24. | ZH22X04000 | [16] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 25. | 2420R349D260 | [1] | HOSE | KOB2600mm Long (102-23/64 in) Superseded by part number: HX21E04260DX |
| 26. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 27. | 2410T323 | [1] | BLOCK | KOB |
| 28. | 2420R349D130 | [2] | FLEXIBLE HOSE | KOB1/4" PF, 1300mm Long (51-3/16 in) |
| 29. | 2436U1169F2 | [2] | VALVE,PILOT | |
| 30. | 2420R349D250 | [8] | HOSE,2500.00 mm | KOB |
| 31. | ZH22X04006 | [8] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 32. | 2416P8607 | [1] | BLOCK | |
| 33. | R44P0086D3 | [8] | CONNECTOR | CONNECTOR |
| 34. | 2444R515D9 | [8] | COUPLING | |
| 35. | ZH22Z04006 | [8] | HYD CONNECTOR | KOB |
| 36. | 2420R349D180 | [2] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 37. | 2420R349D13 | [6] | HOSE | HOSE |
| 38. | 2420R349D9 | [1] | HOSE ASSY | HOSE ASSY |
| 39. | 2420R349D1 | [1] | HOSE ASSY | HOSE ASSY |
| 40. | 2420R349D030 | [2] | HOSE,300.00 mm | KOB |
| 41. | ZH42X04000 | [3] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 42. | ZH52X04000 | [2] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 43. | 2418T17506 | [1] | TUBE | |
| 45. | 2418T17507 | [1] | TUBE | |
| 46. | ZH21M08004 | [6] | HYD CONNECTOR | KOB |
| 47. | ZH31M08006 | [1] | ELBOW | KOB |
| 48. | ZH51K08000 | [3] | TEE | KOB |
| 49. | ZX15K08010 | [2] | TUBE NYLON | TUBE NYLON |
| 50. | ZX15K08260 | [1] | TUBE | KOB |
| 51. | ZX15K08090 | [3] | FLEXIBLE HOSE | KOBTUBE,NYLON |
| 52. | ZX15K08005 | [2] | TUBE | KOB |
| 53. | ZX15K08026 | [1] | TUBE, NYLON | TUBE, NYLON |
| 54. | 2414P4075 | [1] | BRACKET | |
| 55. | 2416T13328 | [1] | BRACKET | |
| 56. | ZS13C12025 | [2] | SCREW | KOBM12x1.75x25mm Superseded by part number: ZS18C12025 |
| 57. | ZS13C10025 | [10] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 58. | ZS13C10035 | [3] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 59. | ZS13C08060 | [2] | CAPSCREW M08x1.25x60mm | CAPSCREW M08x1.25x60mm |
| 61. | ZS23C06012 | [8] | SCREW,Hex Socket Head, M6 x 12mm | KOBM06x1.0x12mm |
| 62. | ZN12C10008 | [3] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 63. | ZN12C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: 77278252, ZN18C08007 |
| 65. | ZW22X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 66. | ZW22X10000 | [13] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 69. | ZW22X06000 | [8] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 70. | 2432T1820 | [1] | LABEL | |
| 71. | 2416P6767 | [1] | BRACKET | |
| 72. | ZS32T40010 | [2] | SCREW | KOBM04x10mm Self-Taper |
| 73. | 2432N1034 | [1] | PLATE | KOB |
| 74. | 2432N1035 | [1] | PLATE, INSTRUCTION | PLATE, INSTRUCTION |
| 75. | 2432N1036 | [1] | PLATE, INSTRUCTION | PLATE, INSTRUCTION |
| 76. | 2432N1037 | [1] | PLATE | KOB |
| 77. | ZH51M08006 | [1] | TEE | KOBCONNECTOR |
| 78. | ZS13C08035 | [2] | SCREW | KOBM08x1.25x35mm Superseded by part number: ZS18C08035 |
| 79. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 80. | ZX15K08023 | [1] | TUBE, NYLON | |
| 81. | 2436U1240F1 | [1] | SOLENOID VALVE | KOB |
| 83. | ZS13C08020 | [2] | SCREW | KOBM08x1.25x20mm Superseded by part number: ZS18C08020 |
| 84. | ZW22X08000 | [6] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 86. | 2444T2524 | [1] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 87. | 2432T1663D1 | [1] | SAND,ALUMINUM | |
| 88. | 2432T1663D2 | [1] | BAND,ALUMINUM | |
| 89. | 2432T1663D3 | [1] | BAND,ALUMINUM | |
| 90. | 2432T1663D4 | [1] | BAND,ALUMINUM | |
| 91. | 2432T1663D5 | [1] | BAND,ALUMINUM | |
| 92. | 2432T1663D6 | [1] | BAND,ALUMINUM | |
| 93. | 2432T1663D7 | [1] | BAND.ALUMINUM | |
| 94. | 2432T1663D8 | [1] | BAND,ALUMINUM | |
