| . . | 24100J6270F2 | [1] | HYDR LINES,UPP | |
| 3. | ZA23F18008 | [7] | HYD CONNECTOR | KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied) |
| 4. | ZA24F18008 | [6] | HYD CONNECTOR | KOB |
| 5. | ZD12P01800 | [30] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 6. | 24I8T12569 | [1] | TUBE | |
| 7. | 2418T17480 | [1] | TUBE | |
| 8. | 2418P11883 | [1] | TUBE | |
| 9. | 2418P12227 | [1] | TUBE | |
| 10. | 2418T17348 | [1] | TUBE | |
| 11. | 2418T12572 | [1] | TUBE | TUBE |
| 12. | 2418T17481 | [1] | TUBE | |
| 13. | 2418T17347 | [1] | TUBE | |
| 14. | 2418T12756 | [1] | TUBE | TUBE |
| 15. | 2418P12049 | [1] | TUBE | |
| 16. | 2418P12229 | [1] | TUBE | |
| 17. | 2418P12230 | [1] | TUBE | |
| 18. | 2418P11888 | [1] | TUBE | |
| 19. | 2418P12228 | [1] | TUBE | |
| 20. | 2418T12576 | [1] | TUBE | |
| 21. | 2418P12060 | [1] | TUBE | |
| 22. | 2418P12240D2 | [2] | TUBE | KOB |
| 23. | 2418P12240D1 | [2] | TUBE | TUBE |
| 24. | 2418P12133 | [1] | TUBE | |
| 24. | 2418P19376 | [1] | TUBE, Serial Range: LE5701-LE5915 | |
| 25. | 2418T17379 | [1] | TUBE, Start Serial: LE5916 | |
| 26. | ZA53B18000 | [3] | TEE | KOB |
| 27. | 2444R950D2 | [4] | FLEXIBLE HOSE | KOB400mm Long (15-3/4 in) |
| 28. | ZA23B18000 | [1] | HYD CONNECTOR | KOB |
| 29. | 2416P8714 | [1] | BRACKET | |
| 30. | ZC36X18011 | [4] | CLAMP | KOB |
| 31. | ZC26X18011 | [3] | CLAMP | KOB Superseded by part number: ZC26M18011 |
| 32. | 2432T2300 | [1] | CLAMP | |
| 33. | ZS13C12030 | [2] | CAPSCREW | KOBSCREW M12x1.75x30mm Superseded by part number: ZS18C12030 |
| 34. | ZS13C10080 | [1] | SCREW | KOBM10x1.50x80mm Superseded by part number: ZS18C10080 |
| 35. | ZS13C10045 | [4] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
| 36. | ZS23C10035 | [6] | SCREW,Hex Socket Head, M10 x 35mm | KOBM10x1.50x35mm |
| 37. | ZN12C10008 | [6] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 38. | ZW22X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 39. | ZW22X10000 | [17] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 40. | 2436R545F1 | [2] | VALVE,CHECK | |
| 41. | 2444Z2349 | [2] | CONNECTOR | CONNECTOR |
| 42. | ZD12P02400 | [9] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 43. | 2418T17455 | [1] | TUBE | |
| 45. | ZA33F18008 | [1] | ELBOW | KOB |
| 46. | 2436R695F1 | [1] | VALVE,CHECK | |
| 47. | 2444Z2393 | [1] | CONNECTOR | |
| 48. | 2436U1224F1 | [1] | VALVE,CONTROL | |
| 49. | 2436U1225F1 | [1] | VALVE,CONTROL | |
| 50. | 2436U1195F1 | [1] | VALVE ASSY | VALVE ASSY |
| 51. | 2436U1196F1 | [1] | SOLENOID VALVE | KOB |
| 52. | 2418P12061 | [1] | TUBE | |
| 53. | 2418P11875 | [1] | TUBE | |
| 54. | 2418T12757 | [1] | TUBE | |
| 55. | 2418T12758 | [1] | TUBE | |
| 56. | 2418T12759 | [1] | TUBE | |
| 57. | 2418P12062 | [1] | TUBE | |
| 58. | 2418P12052 | [1] | TUBE | |
| 59. | 2418T17484 | [1] | TUBE | |
| 60. | 2418T17356 | [1] | TUBE | |
| 61. | 2418T17483 | [1] | TUBE | |
| 62. | 2416T13235 | [1] | BRACKETT | |
| 63. | 2418112768 | [1] | TUBE | |
| 64. | 2418T12769 | [1] | TUBE | |
| 65. | 2418P12063 | [1] | TUBE | |
| 66. | 2418P12053 | [1] | TUBE | |
| 67. | 2418T17358 | [1] | TUBE | |
| 68. | 2418T17389 | [1] | TUBE | |
| 69. | 2418T17359 | [1] | TUBE | |
| 70. | 2418T17252 | [1] | TUBE | |
| 71. | ZH42X08000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 45° -- (Incls. O-Ring ZD12P01800) |
| 72. | ZA23F10006 | [1] | HYD CONNECTOR | KOB |
| 73. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400), Start Serial: LE5773 |
| 74. | 2436U1171D36 | [1] | CHECK VALVE | KOB |
| 75. | 2436R576F3 | [1] | VALVE, CHECK | KOB Superseded by part number: PW21V00003F1 |
| 76. | R44P0089D1 | [2] | COUPLING | KOB Superseded by part number: ZG15F03800 |
| 76-3. | R44P0089D1S3 | [2] | GASKET | KOB |
| 77. | R44P0089D11 | [1] | COUPLING | KOB Superseded by part number: ZG15F03200 |
| 77-3. | R44P0089D11S3 | [2] | GASKET | KOB |
| 78. | R18P0168D34 | [1] | HOSE | KOB |
| 79. | 2420R367D1 | [2] | FLEXIBLE HOSE | KOB |
| 80. | R18P0168D49 | [1] | HOSE | HOSE |
| 81. | 2444R940D1 | [2] | HOSE | KOB |
| 82. | ZX21M08062 | [1] | FLEXIBLE HOSE | KOB620mm Long (24-13/32 in) |
| 83. | 2418T7003D3 | [2] | FLEXIBLE HOSE | KOB |
| 84. | 2418P12237 | [1] | TUBE | |
| 85. | 2418P12238 | [1] | | |
| 86. | ZX15K08030 | [1] | FLEXIBLE HOSE | KOB |
| 87. | ZX15K08140 | [1] | TUBE, NYLON | TUBE, NYLON |
| 88. | ZX15K08035 | [1] | TUBE | KOB |
| 89. | ZX15K08125 | [1] | TUBE,NYLON | |
| 90. | ZX15K08056 | [1] | | |
| 91. | ZA23F22008 | [7] | HYD CONNECTOR | KOB1/2" PT - M30x1.50 x 43mm Long |
| 92. | ZA23F10004 | [1] | HYD CONNECTOR | KOB1/4" PF x M16x1.50 x 33mm Long |
| 93. | ZH21M08008 | [1] | HYD CONNECTOR | KOB |
| 94. | ZA33F22008 | [3] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| 95. | ZA23B22000 | [1] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| 96. | ZH31M08006 | [1] | ELBOW | KOB |
| 97. | ZA53B22000 | [4] | TEE | KOB |
| 98. | ZH51M08006 | [1] | TEE | KOBTEE |
| 99. | ZE12X12000 | [4] | CLAMP | KOB(Incls. Capscrew & Lockwasher) |
| 100. | ZH51K08000 | [3] | TEE | KOB |
| 101. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 102. | ZD12P01100 | [4] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 103. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 104. | 2444Z2397 | [1] | ELEC CONNECTOR | KOB |
| 105. | ZC26X38016 | [3] | CLAMP | |
| 106. | ZC26X22011 | [2] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 107. | 2420T2948D2 | [1] | U-BOLT | KOBM08x1.25x ID 38 x 72mm Long |
| 108. | ZC15X05000 | [8] | CLIP | KOB |
| 109. | ZC15X03600 | [4] | CLIP | KOB |
| 110. | ZS23C08065 | [2] | CAP,Hex Socket Head, M8 x 65mm | KOBScrew -- M08x1.25x65mm |
| 111. | ZS23C06035 | [4] | SCREW,Hex Socket Head, M6 x 35mm | KOBM06x1.0x35mm |
| 112. | ZS23C10030 | [8] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 113. | ZS13C14070 | [3] | SCREW | KOBM14x2.0x70mm Superseded by part number: ZS18C14070 |
| 114. | ZS13C12045 | [2] | SCREW | KOBM12x1.75x45mm Superseded by part number: ZS18C12045 |
| 115. | ZN13C08007 | [4] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 116. | ZN13C12010 | [2] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 117. | ZN13C06005 | [4] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 118. | ZW22X06000 | [4] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 119. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 120. | ZW22K10000 | [16] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 121. | ZW22X14000 | [3] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 122. | ZD12P01400 | [3] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 123. | ZC15X06000 | [8] | CLIP | KOBCLAMP |
| 124. | 2444T2531 | [1] | CONNECTOR | |
| 125. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 126. | 2418T17479 | [1] | TUBE | KOB |
| 127. | 2418T17482 | [1] | TUBE | |
| 128. | ZC15X02600 | [4] | CLAMP | KOB |
| 129. | ZH31M08004 | [3] | ELBOW | KOB |
| 130. | 2444T2517 | [1] | ELBOW | ELBOW |
| 131. | ZA33F10004 | [3] | ELBOW | KOB |
| 132. | ZH22X04006 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 133. | ZH21M08006 | [2] | HYD CONNECTOR | KOBCONNECTOR |
| 134. | ZX25M04070 | [1] | HOSE | KOB |
| 135. | 2416T13236 | [1] | BRACKET | |
| 136. | ZS13C10030 | [2] | SCREW | KOBM10x1.50x30mm Superseded by part number: ZS18C10030 |
| 137. | ZS23C10060 | [8] | SCREW,Hex Socket Head, M10 x 60mm | KOBM10x1.50x60mm |
| 138. | 2418T12389 | [2] | FLANGE | |
| 139. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 140. | 2436R681F1 | [2] | VALVE,CHECK | |
| 141. | 2444T2508 | [1] | HYD CONNECTOR | KOB |
| 142. | ZA33F22012 | [1] | ELBOW | KOB |
| 143. | 2444Z2368 | [1] | HYD CONNECTOR | KOB |
| 144. | ZA33F22012 | [1] | ELBOW | KOB |
| 145. | 2436R576F2 | [1] | VALVE | KOBVALVE,CHECK |
| 147. | ZX25M04120 | [1] | HOSE | KOB |
| 148. | ZX15K08005 | [1] | TUBE | KOB |
| 149. | ZX15K08050 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 150. | ZX15K08022 | [1] | TUBE,NYLON | |
| 151. | ZX15K08007 | [1] | | |
| 152. | ZW11X08000 | [2] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 153. | 2436R696F1 | [1] | VALVE,CHECK | |
| 154. | 2444T2563 | [1] | HYD CONNECTOR | KOB |
| 155. | ZA23H22012 | [1] | HYD CONNECTOR | KOB |
| 156. | 2436U1226F1 | [1] | CONTROL VALVE | KOB |
