神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (04-004) - PUMP ASSY, CONNECT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
310 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2972F1 | [1] | PUMP ASSY, CONNECT | |
| 1. | 2437U185F1 | [1] | PUMP | KOB |
| 2. | 2416N3211 | [1] | BRACKET | |
| 3. | 24100U341F1 | [1] | COUPLING | KOB Superseded by part number: LF30P01001F1 |
| 3-1. | 24100U341S1 | [1] | COUPLING | KOB Superseded by part number: LF30P01001S001 |
| 3-2. | 2418U128S5 | [6] | SCREW | KOBM16x2.0x50mm Long Superseded by part number: LQ30P01003S005 |
| 3-3. | ZP26D05010 | [9] | PIN | KOBRoll -- OD 05 x 10mm Long |
| 4. | 2418P11779 | [1] | HUB,COUPLING | |
| 5. | ZS13C16040 | [2] | SCREW | KOBM16x2.0x40mm |
| 6. | ZS13C10035 | [5] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 7. | 2420T4515D1 | [3] | SCREW | KOB |
| 8. | ZN13C10008 | [3] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 9. | R16T0152D2 | [2] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm |
| 10. | ZW22X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| . . | 24100N2972F2 | [1] | PUMP ASSY,CONNECT | |
| 12. | 2441U291F2 | [1] | HYDRAULIC PUMP | KOB |
| 14. | 2436Z395 | [1] | COUPLING | |
| 15. | 2436Z396 | [1] | SPACER | |
| 16. | ZS23C10060 | [2] | SCREW,Hex Socket Head, M10 x 60mm | KOBM10x1.50x60mm |
| 17. | ZD12G05500 | [1] | O-RING,3.1mm Thk x 54.4mm ID, 90 Duro | KOBO -- ID 54.40 ± 0.49 x OD 60mm |
| 18. | ZR26X01200 | [1] | LOCKING RING | KOBSNAP |
| 20. | ZW11K10000 | [2] | WASHER | KOBID 10 x OD 18 x Th 2.0mm |
| . . | 24100N2972F4 | [1] | PUMP ASSY,CONNECT | |
| 11. | 2437U184F1 | [1] | PUMP | |
