神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (04-012[02]) - PANEL ASSY, INST, (WRIST CONTROL) P/N 24100J6399F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
916 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6399F2 | [1] | PANEL ASSY,INST | |
| 1. | 2416P8565 | [1] | INSTRUMENT PANEL | KOB |
| 2. | 2416N3277 | [1] | BRACKET | |
| 3. | 2414P4073 | [1] | COVER | |
| 4. | 2479U314D2 | [1] | SWITCH | KOB |
| 6. | 2479U317 | [1] | SWITCH | KOB |
| 7. | 2414Z266 | [1] | COVER | KOB |
| 8. | 2479Z956 | [1] | LIGHTER | LIGHTER |
| 9. | 2479U325 | [1] | SWITCH | KOB |
| 10. | 2479U349 | [1] | THERMOSTAT | KOBSWITCH,WIPER |
| 11. | 2479U327 | [1] | SWITCH | KOB |
| 13. | 2479U339 | [1] | THERMOSTAT | KOB |
| 14. | 2479Z849 | [1] | SWITCH | KOB Superseded by part number: 2479Z514 |
| 18. | 2432T2276 | [1] | LABEL | KOB |
| 20. | 2479R708 | [1] | FUSE | KOB |
| 21. | 2479U244 | [2] | SPEAKER | KOB |
| 22. | 2479Z699D8 | [1] | BUZZER | KOB |
| 23. | 4079Z22 | [1] | RELAY | KOB |
| 24. | 2489U178 | [1] | DIPSTICK | KOB |
| 25. | 2479R714F1 | [1] | FUSE BOX | KOB |
| 25-1. | 2479R714S1 | [1] | BODY | KOB |
| 25-2. | 2479R714S2 | [1] | COVER | |
| 25-3. | 2479R714S3 | [7] | FUSE | KOB |
| 26. | 2479U229 | [4] | RELAY | KOB |
| 30. | 2406N784D1 | [1] | LEVER | KOB |
| 31. | 2406Z305 | [1] | GRIP | KOB |
| 32. | 2418T12715 | [1] | WASHER | KOB |
| 33. | ZP26D06032 | [1] | ROLL PIN | KOB |
| 34. | R16T0137D2 | [4] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 1.6mm |
| 35. | R16T0040 | [1] | WASHER | KOB Superseded by part number: 2418T12345, 77266155 |
| 39. | 2406U159 | [1] | CABLE | KOB |
| 39-3. | R06T0042D2 | [2] | END | KOB |
| 39-4. | 2419T3314 | [2] | PIN | KOB |
| 39-5. | ZP15K01610 | [2] | COTTER PIN | KOB Superseded by part number: ZP15K01615 |
| 41. | 2420T4333D7 | [1] | SCREW | KOB |
| 42. | 2417T509 | [1] | SPRING | KOB |
| 43. | 2418T12294 | [1] | WASHER | KOB |
| 44. | 2405Z153D5 | [1] | BUSHING | BUSHING |
| 45. | 2414T3609 | [1] | COVER | KOB |
| 46. | 2414T3570 | [1] | COVER | COVER |
| 47. | 2418T15332 | [1] | PLATE | |
| 48. | 2416P8633 | [1] | BOX | BOX |
| 50. | 2479U337F1 | [1] | GAUGE | KOBGAUGE,CLUSTER |
| 51. | 2420Z1617 | [1] | PLUG | KOB |
| 52. | 2420R372D120 | [1] | GROMMET | GROMMET |
| 54. | 2420R429D4 | [1] | GROMMET | KOB |
| 55. | 2420R429D15 | [6] | GROMMET | KOB |
| 56. | 2420R429D14 | [2] | GROMMET | KOB |
| 57. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 58. | ZS18C06012 | [4] | SCREW,Hex, M6 x 12mm | KOBM06x1.0x12mm |
| 59. | ZS31C06012 | [16] | SCREW,Phillips Drive, Pan HD, M6 x 12mm | KOBM06x1.0x12mm |
| 60. | ZS31C05016 | [2] | BOLT,Phillips Drive, Pan HD, M5 x 16mm | KOBM05x0.8x16mm |
| 61. | ZS31C04010 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 10mm | KOBM04x0.7x10mm |
| 62. | ZS41C0602S | [4] | MACHINESCREW | |
| 63. | ZN11C12007 | [2] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12007 |
| 64. | ZN17C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 66. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 67. | ZW16K06000 | [20] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 68. | ZW16K05000 | [2] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 69. | ZW16K04000 | [2] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 70. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 71. | ZW26X06000 | [20] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 72. | ZW26X05000 | [2] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 73. | ZW26X04000 | [2] | LOCK WASHER | KOBID 04 x OD 7.6 x Th 1.0mm |
| 74. | ZS32T35006 | [1] | SELF-TAP SCREW | KOB |
| 76. | R16T0063D3 | [1] | GROMMET | KOB |
| 16. | VI98253010800 | [1] | RESISTOR | KOBCONTROL -- ISUZU ENGINE PARTS Superseded by part number: VI9825301080 |
| 17. | VI98271022700 | [1] | SWITCH,STARTER -- ISUZU ENGINE PARTS | |
| 19. | VI89445504300 | [1] | RELAY -- ISUZU ENGINE PARTS | |
| 29. | VI89445017400 | [1] | SAFETY RELAY -- ISUZU ENGINE PARTS | |
