现代零件查询R360LC-7A MAIN CONTROL VALVE(4/4, TYPE 2, #0170-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
979 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| 155. |
XJBN-00814
|
[1] |
PLUG
|
|
| 165. |
XJBN-00233
|
[1] |
O-RING
|
|
| 202. |
XJBN-01284
|
[4] |
COVER-SPRING
|
|
| 208. |
XJBN-01289
|
[1] |
COVER-SPOOL
|
|
| 211. |
XJBN-01290
|
[1] |
PLUG
|
|
| 212. |
XJBN-00045
|
[1] |
O-RING
|
|
| 251. |
XJBN-01291
|
[1] |
PLUG
|
|
| 262. |
XJBN-00493
|
[4] |
O-RING
|
|
| 263. |
XJBN-01293
|
[5] |
O-RING
|
|
| 265. |
XJBN-01294
|
[1] |
O-RING
|
|
| 273. |
XJBN-00700
|
[10] |
SCREW-HEX
|
|
| 301. |
XJBN-01345
|
[1] |
SPOOL KIT-TRAVEL
|
|
| 303. |
XJBN-01347
|
[1] |
SPOOL KIT-BOOM
|
|
| 304. |
XJBN-01348
|
[1] |
SPOOL KIT-BUCKET
|
|
| 313. |
XJBN-01302
|
[1] |
PLUG
|
|
| 326. |
XJBN-01303
|
[1] |
SPRING
|
|
| 327. |
XJBN-01304
|
[1] |
SPRING
|
|
| 337. |
XJBN-01308
|
[1] |
ROD
|
|
| 391. |
XJBN-01351
|
[1] |
SPOOL KIT-T/STRAIGHT
|
|
| 392. |
XJBN-01316
|
[1] |
SPOOL-BY PASS CUT
|
|
| 394. |
XJBN-01353
|
[1] |
SPOOL KIT-A/CONFLUENCE
|
|
| 551. |
XJBN-01326
|
[1] |
PLUG
|
|
| 561. |
XJBN-01330
|
[1] |
O-RING
|
|
| 603. |
XJBN-01332
|
[2] |
PORT RELIEF ASSY
|
|
| 604. |
XJBN-01333
|
[1] |
PORT RELIEF ASSY
|
|
| 611. |
XJBN-01335
|
[1] |
NEGATIVE RELIEF VLV ASSY
|
|
| 754. |
XJBN-01339
|
[1] |
FLANGE
|
|
| 763. |
XJBN-01341
|
[1] |
O-RING
|
|
| 764. |
XJBN-01235
|
[4] |
SCREW-SOCKET
|
|
