神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (06-001[02B]) - BOOM ASSY, 3.65M (11FT 11IN) P/N 24100J6139F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
289 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6139F3 | [1] | | |
| 2. | 2438U717F3 | [1] | CYLINDER | KOB |
| 5. | 2406P2563D1 | [1] | LINK | KOB |
| 6. | 2406P2563D2 | [1] | LINK | KOB |
| 7. | 2419P1664D1 | [2] | PIN | KOB |
| 11. | 2418P11922 | [1] | TUBE | KOB |
| 12. | 2418P11923 | [1] | RIGID TUBE | KOB |
| 13. | 2416T3204 | [2] | CLAMP | KOB |
| 14. | 2445R138D1 | [6] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
| 15. | 2445R138D3 | [2] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 16. | 2445R220D5 | [4] | SEAL,50mm ID x 65mm OD x 5mm Thk | KOBDust -- ID 50 x OD 65 x Th 5mm Superseded by part number: 71436184 |
| 17. | 2444R950D6 | [2] | HOSE | KOB |
| 18. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 19. | ZG91U02000 | [2] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 20. | ZF23E18008 | [2] | HYD CONNECTOR | KOB |
| 21. | ZS13C12110 | [6] | SCREW | KOBM12x1.75x110mm Superseded by part number: ZS18C12110 |
| 22. | ZS13C08030 | [4] | SCREW | KOBM08x1.25x30mm Superseded by part number: ZS18C08030 |
| 23. | ZN12C12010 | [12] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 24. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 25. | 2416T8738 | [1] | SPACER | KOB |
| 27. | 2406P2606D1F1 | [1] | LINK, BUCKET | LINK, BUCKET |
| 27-4. | 2405T596C2 | [1] | BUSHING | KOB |
| 27-5. | 2405T632C2 | [1] | BUSHING | KOB |
| 28. | 2406P2606D2F1 | [1] | LINK | KOB |
| 28-4. | 2405T596C2 | [1] | BUSHING | KOB |
| 28-5. | 2405T632C2 | [1] | BUSHING | KOB |
| 29. | 2419P1695 | [2] | PIN | KOB |
| 30. | 2411N1443F1 | [1] | ARM | |
| 30-3. | 2405P477 | [2] | BUSHING | KOB |
| 30-4. | 2405T594C2 | [2] | BUSHING | KOB |
| 30-5. | 2405T595C2 | [2] | BUSHING | KOB |
| 30-6. | 2418T10842 | [1] | SPACER | KOB |
| 30-7. | 2418T10843 | [1] | SPACER | KOB |
| 31. | 2419P1724 | [1] | PIN | KOB |
| 32. | 2419T4702 | [1] | PIN | PIN |
