现代零件查询R360LC-7A PILOT HYD PIP(BASE 3,MCV TYPE1,#0746-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
587 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
PILOT HYD PIPING
|
|
| 5. |
X500-110001
|
[4] |
CONNECTOR-ORFS
|
|
| 15. |
X520-110001
|
[5] |
ELBOW-90,ORFS
|
|
| 19. |
X520-110012
|
[2] |
ELBOW-90,ORFS
|
|
| 23. |
X530-110001
|
[1] |
ELBOW-45,ORFS
|
|
| 24. |
X810-045151
|
[1] |
TEE-B/TYPE,ORFS
|
|
| 25. |
X820-045151
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 29. |
X840-525152
|
[1] |
TEE-R/TYPE,SWIVEL,ORFS
|
|
| 36. |
S551-050203
|
[30] |
CLAMP-BAND
|
|
| 49. |
X400-042018
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 50. |
X400-042021
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 51. |
X400-042024
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 56. |
X410-042008
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 57. |
X420-042009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 58. |
X420-042011
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 59. |
X420-042013
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 60. |
X420-042015
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 61. |
X420-042018
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 63. |
X420-042023
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 64. |
X420-042025
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| P1. |
S631-011004
|
[12] |
O-RING
|
|
| P2. |
S631-014004
|
[2] |
O-RING
|
|
| 01. |
S621-011001
|
[18] |
O-RING
|
|
| 02. |
S621-012001
|
[4] |
O-RING
|
|
