神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (08-011) - GRAPPLE ASSY, FORK (SINGLE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
677 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6201F1 | [1] | GRAPPLE ASSY,FORK | |
| 1. | 2412J686F1 | [1] | GRAPPLE | |
| 1-1. | 2412J686 | [1] | GRAPPLE | |
| 1-18. | 2405T873 | [4] | BUSHING | KOB |
| 2. | 2412J687 | [1] | GRAPPLE | |
| 3. | 2406P2573D1F1 | [1] | LINK,IDLES | |
| 3-1. | 2406P2573D1 | [1] | LINK,IDLES | |
| 3-5. | 2405T596C2 | [1] | BUSHING | KOB |
| 4. | 2406P2573D2F1 | [1] | LINK,IDLES | |
| 4-1. | 2406P2573D2 | [1] | LINK,IDLES | |
| 4-5. | 2405T596C2 | [1] | BUSHING | KOB |
| 5. | 2419T3837 | [2] | PIN | |
| 6. | 2419P1565D4 | [1] | PIN | |
| 7. | ZG91S02000 | [7] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 8. | 2445R138D1 | [4] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
| 9. | 2445Z912 | [4] | O-RING | KOBID 90 ± 0.40 x OD 108mm |
| 10. | ZS13C12110 | [4] | SCREW | KOBM12x1.75x110mm Superseded by part number: ZS18C12110 |
| 11. | ZN17C12010 | [8] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
