神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (01-002) - CYLINDER HEAD & OTHER PARTS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
818 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8941214339 | [1] | BLOCK ASM. CYL. | |
| 1-1. | VI8941214359 | [1] | BLOCK ASM. CYL. | |
| 1-2. | VI8941698791 | [1] | BLOCK ASM. CYL. | |
| 2. | VI8942478610 | [4] | LINER CYL. | |
| 2-1. | VI8941101440 | [4] | LINER CYL. | |
| 2-2. | VI8941698830 | [4] | LINER CYL. | |
| 3. | VI9098026301 | [10] | BOLT | |
| 5. | VI8941685561 | [1] | SET OF STD MAIN BRGS | KOBBEARING SET CAM Superseded by part number: VI8973781480 |
| 6. | VI5112190180 | [1] | SEAL | KOBSEALING CUP |
| 6-1. | VI5112190170 | [1] | CUP | KOBSEALING CUP |
| 6-2. | VI5112190080 | [3] | SEAL | KOBSEALING CUP |
| 6-3. | VI1096000051 | [3] | CUP | KOBSEALING CUP Superseded by part number: 87398694 |
| 6-4. | VI5096000130 | [1] | CUP | KOBSEALING CUP Superseded by part number: VI8970363351 |
| 6-5. | VI5112190150 | [2] | CUP | KOBSEALING CUP Superseded by part number: VI1096000121 |
| 7. | VI8941337651 | [1] | DUCT WATER | |
| 8. | VI3942505140 | [1] | SEALING CUP | |
| 9. | VI5112190180 | [3] | SEAL | KOBSEALING CUP |
| 10. | VI5111290060 | [2] | SEAL | KOBSEALING CUP |
| 11. | VI5111290030 | [1] | SEAL | KOBSEALING CUP |
| 12. | VI5096050192 | [1] | PLUG | KOBPLUG TAPPER, OIL GALLERY |
| 12-1. | VI5096050192 | [1] | PLUG | KOBPLUG TAPPER, OIL GALLERY |
| 13. | VI9992023140 | [1] | PLUG | KOBPLUG NO. 4 GALLERY |
| 14. | VI9095714140 | [1] | GASKET | KOBPACKING PLUG |
| 15. | VI8941781530 | [1] | PIPE, WATER DRAIN | |
| 16. | VI9992023160 | [1] | PLUG | KOBPLUG SCREW, OIL JET Superseded by part number: VI0920024160 |
| 17. | VI9095714160 | [1] | SEAL | KOBPACKING PLUG |
| 18. | VI8941567950 | [1] | COVER WATER | |
| 19. | VI8941718980 | [1] | O-RING | KOBPACKING WATER INLET |
| 20. | VI9019108180 | [2] | SCREW | KOBBOLT SEMS, COVER |
| 21. | VI8942149130 | [1] | SEAL OIL, CRANK, R.R | |
| 22. | VI8941300211 | [1] | LUBE NIPPLE | KOBNIPPLE, INJ, PUMP |
| 23. | VI9098785970 | [2] | PIN CYL, BLOCK | |
| 24. | VI9112290490 | [2] | DOWEL CYL, BLOCK | |
| 25. | VI9081510200 | [1] | PIN | KOBPIN STRAIGHT, F, PLATE |
| 25-1. | VI9081510500 | [1] | PIN STRAIGHT, F, PLATE | |
| 26. | VI8941421530 | [1] | PLATE F, CYL. BLOCK | |
| 26-1. | VI8941701081 | [1] | PLATE F, CYL. BLOCK | |
| 27. | VI8941421620 | [1] | UNDER PLATE | |
| 28. | VI9058210450 | [2] | BOLT SOCKET | |
| 29. | VI8941293361 | [1] | PACKING F, PLATE | |
| 30. | VI9112290580 | [1] | DOWEL PLATE | |
| 31. | VI9041108250 | [2] | STUD | KOBSTUD NUT, PTO COVER Superseded by part number: VI0410108250 |
| 31. | VI9041108400 | [1] | STUD | KOBSTUD NUT, PTO COVER |
| 31. | VI5093000620 | [1] | STUD NUT, GEAR CASE | |
| 31-1. | VI9019108350 | [1] | BOLT SEMS, FRONT PLATE | |
| 31-2. | VI9019108220 | [6] | BOLT BOLT SEMS, FRONT PLATE | BOLT BOLT SEMS, FRONT PLATE |
| 31-3. | VI9019108220 | [7] | BOLT BOLT SEMS, FRONT PLATE | BOLT BOLT SEMS, FRONT PLATE |
| 32. | VI9041108250 | [2] | STUD | KOBSTUD NUT, PTO COVER Superseded by part number: VI0410108250 |
| 33. | VI5137210430 | [1] | DRAIN PIPE WATER | |
| 35. | VI9099022380 | [2] | CONNECTION | KOBADAPTER |
| 37. | VI9095720080 | [1] | GASKET | KOBPACKING NIPPLE |
| 38. | VI9081610320 | [1] | PIN | KOBPIN STRAIGHT, RR, PLATE |
| 40. | VI8941719430 | [1] | BOLT REAMER | |
| 40-1. | VI9096065350 | [1] | BOLT | KOBBOLT REAMER |
| 40-2. | VI9891129110 | [1] | BOLT REAMER | |
| 41. | VI8941293051 | [1] | PLATE RR. | |
| 41-1. | VI8941701071 | [1] | PLATE RR. | |
| 41-2. | VI8944181551 | [1] | PLATE RR. | |
| 42. | VI5090002770 | [3] | BOLT RR. PLATE | |
| 42-1. | VI8941752760 | [3] | BOLT RR. PLATE | |
| 43. | VI9020610300 | [3] | BOLT RR. PLATE | |
| 43-1. | VI9019110250 | [3] | BOLT | KOBBOLT RR. PLATE Superseded by part number: VI0500410250 |
| 44. | VI9091508100 | [3] | WASHER SPR. | |
| 45. | VI9023612350 | [4] | BOLT RR. PLATE | |
| 45-1. | VI9019112300 | [2] | BOLT RR. PLATE | |
| 46. | VI9091508120 | [4] | WASHER SPR. | |
| 47. | VI9081512220 | [2] | PIN, RR. PLATE | |
| 47-1. | VI9081610220 | [2] | PIN, RR. PLATE | |
| 48. | VI9091104100 | [1] | NUT | KOB Superseded by part number: VI9091105100 |
| 49. | VI9091508100 | [1] | WASHER SPR. | |
| 50. | VI8944226000 | [1] | WATER DRAIN COCK ASM. | |
| 50-1. | VI8944294210 | [1] | WATER DRAIN COCK ASM. | |
| 51. | VI9099145380 | [1] | PIPE VINYL, WATER DRAIN | |
| 51-1. | VI9099138340 | [1] | PIPE VINYL | |
| 52. | VI9097150130 | [1] | CLIP WATER | |
| 53. | VI8944110010 | [2] | STUD RR. PLATE | |
| 54. | VI9096640010 | [1] | PLUG | KOBPLUG WATER DRAIN |
