凯斯零件查询(LB424S) - BALER (9/12-) (88.070.011[01]) - SERVICE KIT : STANDARD AND PARTIAL BALE EJECTION MECHANISM - C084 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
267 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47639120
|
[1] |
KIT
|
ZED
Incl 2 - 28
|
| 2. |
47480763
|
[1] |
CROSSRAIL
|
ZED
|
| 3. |
47449746
|
[1] |
CROSSRAIL
|
ZED
|
| 4. |
47440012
|
[1] |
LATH
|
ZED
|
| 5. |
47440688
|
[1] |
LATH
|
ZED
|
| 6. |
47440696
|
[1] |
LATH
|
ZED
|
| 7. |
47440650
|
[1] |
LATH
|
ZED
|
| 8. |
47656374
|
[1] |
PROFILE
|
ZED
|
| 9. |
47656378
|
[1] |
PROFILE
|
ZED
|
| 10. |
47440747
|
[2] |
SHIM,108mm OD x 1mm Thk
|
ZED
|
| 11. |
47440745
|
[2] |
SHIM,108mm OD x 2mm Thk
|
ZED
|
| 12. |
84570796
|
[2] |
SHIM,45mm OD x 1.07mm Thk
|
ZED
|
| 13. |
84570801
|
[2] |
SHIM,45mm OD x 1.91mm Thk
|
ZED
|
| 14. |
84145759
|
[14] |
TOOTH
|
ZED
|
| 15. |
47449895
|
[2] |
LATH
|
ZED
|
| 16. |
47449897
|
[2] |
LATH
|
ZED
|
| 17. |
300389
|
[4] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 18. |
87314103
|
[12] |
PLOW BOLT,M12 x 1.75 x 40mm, Cl 10.9
|
CAS
|
| 19. |
100038
|
[12] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 20. |
47433591
|
[2] |
BLOCK
|
ZED
|
| 21. |
386045
|
[4] |
BOLT,Hex, M8 x 1.25 x 45mm, Cl 8.8
|
NH
Superseded by part number: 16044124
|
| 22. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 23. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 24. |
412327
|
[8] |
CARRIAGE BOLT,Short Sq Nk, M6 x 1 x 40mm, Full Thd, Cl 8.8
|
NH
|
| 25. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 26. |
9706755
|
[8] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 27. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 28. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
