| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10843F3 | [1] | LABEL,NAME-PLATE,(STD) | |
| . . | 24100J10843F4 | [1] | LABEL,NAME-PLATE,(L C) | |
| 2. | 2432N1165 | [1] | NAME-PLATE | |
| 3. | 2432N1159 | [2] | LABEL | KOB |
| 4. | 2432T4153 | [1] | LABEL | KOB |
| 5. | 2432T4151 | [1] | TYPE PLATE | KOBNAME-PLATE |
| 6. | 2432T4154 | [1] | LABEL | KOB |
| 7. | 2432T4257 | [1] | LABEL | |
| 8. | 2432N1158 | [1] | NAME-PLATE | |
| 9. | 2432T4152 | [1] | TYPE PLATE | KOBNAME-PLATE |
| 10. | 2427Z329D2 | [1] | SHEET | KOBAnti-Slip (400x150mm) |
| 11. | 2427Z329 | [3] | SHEET | KOBAnti-Slip (300x150mm) |
| 12. | 2432T114203 | [4] | LABEL | |
| 13. | 2432T884 | [1] | LABEL | KOB |
| 14. | 2446U228S12 | [1] | LABEL | KOB |
| 16. | 2432P1031 | [1] | LABEL | LABEL |
| 17. | 2432P1039 | [1] | LABEL | LABEL |
| 18. | 2432T2471 | [1] | LABEL | LABEL |
| 19. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 20. | 2432T1530 | [1] | IDENTITY PLATE | KOB |
| 21. | 2432J1354 | [1] | TYPE PLATE | KOB |
| 22. | 2432T1759 | [1] | PLATE | KOB |
| 24. | 2432T1753 | [1] | LABEL | KOBDecal, Kobelco Operation Superseded by part number: YN20T01407P1 |
| 25. | 2432N568 | [1] | INSTALLER JIG | KOB Superseded by part number: 2432N1751 |
| 26. | 2432N578 | [1] | PLATE | KOB |
| 27. | 2432N696 | [1] | INSTALLER JIG | KOB Superseded by part number: 2432N1750 |
| 28. | 2432N1084 | [1] | INSTALLER JIG | KOB Superseded by part number: 2432N1752 |
| 29. | 2432Z287 | [1] | LABEL | KOB Superseded by part number: YN20T01408P1 |
| 30. | 2432T2991D1 | [1] | LABEL | KOB(ANTIFREEZE) |
| 31. | 2432T2337 | [1] | LABEL | LABEL |
| 33. | 2432N563 | [1] | LABEL (STAY OUT) | |
| 34. | 2432T888 | [1] | PLATE, CAUTION | PLATE, CAUTION |
| 35. | 2432T2283 | [1] | LABEL | KOBDecal, Fuel location |
| 36. | 2432T2338 | [1] | LABEL | LABEL |
| 37. | 2432P1038 | [1] | TYPE PLATE | KOB |
| 38. | 2432T2486 | [1] | LABEL | KOB |
| 39. | 2432T2485 | [1] | LABEL | KOB |
| 40. | 2432T2304D11 | [2] | LABEL | KOB |
| 41. | 2432T4258 | [1] | LABEL | KOB |
| 42. | 2432T4259 | [1] | LABEL | KOB |
| 43. | 2432T2487 | [1] | LABEL | KOB |
| 44. | 2432T2304D17 | [1] | LABEL | KOB |
| 45. | 2432Z470 | [1] | LABEL | KOB Superseded by part number: YT20T01036P1 |
| 46. | 2432T2521 | [1] | LABEL | LABEL |
| 47. | 2418T10311 | [2] | PLATE | KOBØ30mm round Superseded by part number: 2418T27058 |
| 48. | 2432N1190 | [1] | LABEL | LABEL |
| 49. | 2432N1367D2 | [1] | LABLE | |
| 50. | 2432T4142 | [1] | LABEL | KOB |
| 54. | 2432J1383 | [2] | NAME-PLATE,(STD) | |
| . . | 2432J1384 | [2] | NAME-PLATE,(1 C) | |
| 55. | 2432N2031 | [1] | LABEL (LUBRICATION),(STD) | |
| . . | 2432N2032 | [1] | LABEL (LUBRICATION),(L C) | |
| 56. | 2432P1058 | [1] | LABEL,(STD) | |
| . . | 2432P1059 | [1] | LABEL,(L C) | |
