凯斯零件查询(LB424S XL) - BALER (11/16-) (05.100.04[02]) - MAINTENANCE PARTS, PICK-UP FRAME, PICK-UP, REEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
708 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84438926
|
[4] |
BALL BEARING,35mm ID x 72mm OD x 17mm W
|
NH
|
| 2. |
84274387
|
[27] |
BRACKET
|
ZED
|
| 3. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
, Serial Range: -C136
|
| 4. |
84056924
|
[4] |
CAM FOLLOWER,Tine Shaft
|
ZED
|
| 5. |
54770
|
[1] |
BALL BEARING,27.33 mm ID x 47.092 mm OD x 25.4 mm
|
NH
, Serial Range: -C136 Superseded by part number: 84330047
|
| 5. |
47523018
|
[1] |
BALL BEARING
|
ZED
, Start Serial: D137
|
| 6. |
136521
|
[1] |
COTTER PIN,5.7mm OD x 44.45mm L
|
NH
, Serial Range: -C136
|
| 6. |
300423
|
[1] |
COTTER PIN,M6.3 x 50
|
WIN
, Start Serial: D137
|
| 7. |
54695
|
[1] |
BEARING HOUSING
|
NH
, Serial Range: -C136
|
| 7. |
47521709
|
[1] |
FLANGE
|
ZED
, Start Serial: D137
|
| 8. |
442245
|
[1] |
WASHER,35mm ID x 51.5mm OD x 0.8mm Thk
|
ZED
, Serial Range: -C136
|
| 9. |
84427925
|
[1] |
TOOTH
|
PLO
, Serial Range: -C084
|
| 9. |
86627654
|
[1] |
SPACER
|
NH
, Serial Range: -F085098 Superseded by part number: 84427925
|
| 9. |
84382002
|
[1] |
SUPPORT
|
ZED
, Serial Range: -F099136
|
| 9. |
84388371
|
[1] |
SPACER
|
PLO
, Start Serial: D137
|
| 10. |
87643386
|
[1] |
BRACKET
|
NH
, Serial Range: -C136
|
| 11. |
84301451
|
[1] |
REEL TINE
|
ZED
4.75 mm, Serial Range: -C098
|
| 11. |
84582461
|
[1] |
TINE
|
ZED
5.5 mm, Start Serial: D099
|
| 12. |
535866
|
[1] |
SCREW
|
GI
, Serial Range: -C136
|
| 13. |
84078001
|
[8] |
COLLAR CLAMP
|
ZED
, Serial Range: -C136
|
| 15. |
84274384
|
[27] |
BRACKET
|
ZED
|
| 16. |
84460596
|
[4] |
ROLLER
|
PLO
|
| 19. |
84392369
|
[36] |
REEL TINE
|
ZED
|
| 20. |
84392367
|
[1] |
REEL TINE
|
ZED
Inside
|
| 21. |
120061
|
[1] |
BOLT,Hex, M8 x 60mm L, Cl 8.8
|
NH
, Start Serial: D137
|
| 22. |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
, Start Serial: D137 Superseded by part number: 83990583
|
| 23. |
84524588
|
[1] |
GUARD
|
PLO
, Start Serial: D137
|
