| . . | 2436U1271F1 | [1] | VALVE, CONTROL VALVE ASSY.CONTROL | VALVE, CONTROL VALVE ASSY.CONTROL |
| . . | 2436U1271F2 | [1] | VALVE, CONTROL VALVE ASSY.CONTROL | VALVE, CONTROL VALVE ASSY.CONTROL |
| 1. | 2436R819F1 | [6] | VALVE PRESSURE RELIE | KOB Superseded by part number: 2436R837F2 |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 102. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 151. | 2436U1219S153 | [1] | PLUG | KOB |
| 152. | 2436U1165S152 | [22] | PLUG | KOB |
| 153. | 2441U732S461 | [4] | PLUG | KOBPLUG Superseded by part number: 2436U2080S8 |
| 154. | 2436U1165S154 | [6] | PLUG | KOB |
| 155. | 2436U1207S851 | [2] | PLUG | KOB |
| 156. | 2436U1265S156 | [1] | PLUG | |
| 157. | 2436U1165S157 | [3] | PLUG | KOB Superseded by part number: 2436U1265S157 |
| 158. | 2436U1207S155 | [5] | PLUG | KOB |
| 159. | 2436U1265S159 | [5] | ORIFICE | |
| 161. | ZD12G03000 | [6] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 162. | ZD12P01000 | [27] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 164. | ZD12P01400 | [6] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 165. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 166. | ZD12P01100 | [4] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 167. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 168. | ZD12P00800 | [5] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 201. | 2436U1265S20S | [2] | COVER.SPRING | |
| 202. | 2436U1265S202 | [2] | COVER | |
| 203. | 2436U1265S203 | [3] | COVER | KOB |
| 204. | 2436U1265S204 | [4] | PLATE | KOBPLATE |
| 206. | 2436U1265S206 | [1] | COVER | |
| 2S1. | 2436U1165S251 | [6] | PLUG | KOB |
| 261. | 2436U1265S261 | [3] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 262. | 2436U1265S262 | [4] | PACKING | KOB |
| 263. | ZD12G03500 | [3] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 265. | ZD12G02500 | [6] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 271. | ZS23C08012 | [6] | SCREW,Hex Socket Head, M8 x 12mm | KOBM08x1.25x12mm |
| 273. | ZS23C08025 | [16] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 301. | 2436U1265S301 | [2] | SPOOL | KOB |
| 302. | 2436U1265S302 | [1] | SPOOL | KOB |
| 303. | 2436U1271S303 | [1] | SPOOL | |
| 304. | 2436U1271S304 | [1] | SPOOL | KOB |
| 305. | 2436U1265S305 | [1] | SPOOL | |
| 306. | 2436U1265S306 | [2] | SPOOL | |
| 307. | 2436U1265S307 | [2] | SPOOL | KOB |
| 308. | 2436R771F1 | [1] | VALVE ASSY.RELIEF(SEE. P.2436R771 -1.2 ) | |
| 321. | 2436U1265S321 | [2] | SPRING | KOB |
| 322. | 2436U1265S322 | [3] | SPRING | KOB |
| 323. | 2436U1265S323 | [3] | SPRING | KOB |
| 324. | 2436U1265S324 | [1] | SPRING | SPRING |
| 326. | 2436U1265S326 | [2] | SPRING | KOB |
| 327. | 2436U1265S327 | [2] | SPRING | KOB |
| 328. | 2436U1265S328 | [2] | SPRING | KOB |
| 331. | 2436U1265S331 | [4] | SPRING SEAT | KOB |
| 332. | 2436U1265S332 | [6] | SPRING SEAT | KOB |
| 334. | ZW11P08000 | [2] | WASHER | KOB Superseded by part number: ZW16P08000 |
| 335. | 2436U1265S335 | [3] | STOP | KOB |
| 336. | 2436U1265S336 | [3] | BOLT | KOB |
| 337. | 2436U1265S337 | [3] | ROD | KOB |
| 338. | 2436U1265S338 | [2] | ROD | KOB |
| 351. | 2436U1165S351 | [1] | ORIFICE | KOB |
| 353. | 2436U1265S353 | [2] | SHIM | SHIM |
| 355. | 2436U1165S355 | [1] | PISTON | KOB Superseded by part number: 2436U1265S355 |
| 511. | 2436U1265S511 | [9] | POPPET | KOB |
| 512. | 2483U172S19 | [5] | BALL | KOB |
| 513. | 2436U1265S513 | [1] | POPPET | POPPET |
| 521. | 2436U1265S521 | [9] | SPRING | KOB |
| 542. | 2436U1265S542 | [3] | SEAT/SLOT | KOB |
| 543. | 2436U1265S543 | [1] | SEAT/SLOT | KOB |
| 544. | 2436U1265S544 | [2] | SEAT | KOB Superseded by part number: 2436U1439S544 |
| 551. | 2436U1265S551 | [11] | PLUG | KOB |
| 552. | 2436U585S651 | [13] | PLUG | KOB Superseded by part number: YT30V00009S153 |
| 553. | 2436U1265S553 | [1] | PLUG | |
| 561. | ZD12P02000 | [11] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 601. | 2436R682F4 | [2] | VALVE PRESSURE RELIE | KOB(SEE. P.2436R682-1 .2 ) Superseded by part number: 2436R839F3 |
| 602. | 2436R683F4 | [2] | VALVE PRESSURE RELIE | KOB( SEE. P.2436R683-1 .2 ) |
| 603. | 2436R684F5 | [2] | VALVE ASSY, RELIEF (SEE. P.2436R684-1 .2 )(F1 ONLY) | VALVE ASSY, RELIEF (SEE. P.2436R684-1 .2 )(F1 ONLY) |
| 604. | 2436R768F1 | [4] | VALVE PRESSURE RELIE | KOB(SEE. P.2436R768-1 .2 )(F1 ONLY) Superseded by part number: 2436R837F2 |
| 611. | 2436R769F1 | [2] | VALVE | KOB(SEE. P.2436R769-1 ,2 ) |
| 612. | 2436U1165S612 | [1] | POPPET | |
| 971. | 2436U1265S971 | [1] | CAPSCREW | |
| 972. | 2436U1265S972 | [1] | CAPSCREW | |
| 973. | 2436U1265S973 | [2] | CAPSCREW | |
| 974. | 2436U1265S974 | [1] | CAPSCREW | |
| 975. | 2436U1265S975 | [1] | CAPSCREW | |
| 976. | 2436U1265S976 | [1] | CAPSCREW | |
| 991. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
