现代零件查询R36N-7 TRAVEL VALVEEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
992 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01952
|
[1] |
VALVE-PILOT
|
|
| 101. |
XJDH-03331
|
[4] |
PACKING
|
|
| 102. |
XJDH-03332
|
[4] |
O-RING
|
|
| 103. |
XJDH-03333
|
[4] |
O-RING
|
|
| 104. |
XJDH-02918
|
[2] |
O-RING
|
|
| 105. |
XJDH-03334
|
[3] |
RO-PLUG
|
|
| 106. |
XJDH-03335
|
[2] |
PLUG
|
|
| 107. |
XJDH-00328
|
[3] |
O-RING
|
|
| 108. |
XJDH-03336
|
[4] |
BOLT-SOCKET HEAD
|
|
| 109. |
XJDH-03337
|
[4] |
SPRING
|
|
| 110. |
XJDH-03338
|
[4] |
SPRING
|
|
| 111. |
XJDH-03339
|
[4] |
SPRING
|
|
| 112. |
XJDH-03340
|
[2] |
SET SCREW
|
|
| 113. |
XJDH-03341
|
[2] |
BELLOWS
|
|
| 2. |
XJDH-00058
|
[4] |
BOLT
|
|
| 3. |
XJDH-00278
|
[4] |
WASHER
|
|
| 4. |
XJDH-00467
|
[3] |
ELBOW-MALE 90
|
|
| 5. |
XJDH-00445
|
[1] |
CONNECTOR-MALE
|
|
| 6. |
XJDH-00480
|
[2] |
ADAPTER-LONG 90
|
|
