| 1. |
47999146
|
[1] |
SUPPORT
|
ZED
|
| 2. |
84547204
|
[1] |
HOLDER
|
ZED
|
| 3. |
84423225
|
[1] |
RESERVOIR
|
ZED
Superseded by part number: 920018985
|
| 4. |
84423241
|
[1] |
STRAP
|
ZED
|
| 5. |
84593003
|
[1] |
TOOL BOX
|
ZED
|
| 6. |
84593010
|
[1] |
DOOR
|
ZED
|
| 7. |
47368966
|
[1] |
RUBBER PAD
|
ZED
|
| 8. |
120044
|
[7] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 9. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 10. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 11. |
328754
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 12. |
86507486
|
[6] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 14. |
9706690
|
[6] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 15. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 16. |
84593007
|
[2] |
SUPPORT
|
ZED
|
| 17. |
84818088
|
[2] |
LOCK
|
ZED
|
| 18. |
120104
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 19. |
378243
|
[2] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
| 20. |
86629542
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 21. |
86512439
|
[6] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 22. |
322357
|
[4] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 23. |
47368910
|
[2] |
CHAIN,Tool Box Door, 648mm L
|
ZED
|
| 24. |
140015
|
[2] |
WASHER,6.4mm ID x 14mm OD x 1.6mm Thk
|
NH
Superseded by part number: 9820463
|
| 25. |
353308
|
[2] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 26. |
87033737
|
[2] |
WASHER,9mm ID x 28mm OD x 3mm Thk
|
BRR
|
| 27. |
9706755
|
[4] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 28. |
84005450
|
[2] |
COMPRESSION SPRING,Compression, 11.13mm OD x 38.1mm L
|
ZED
|
| 29. |
84607251
|
[1] |
RUBBER WEATHERSTRIP
|
ZED
L = 2156 MM Superseded by part number: 84818178
|
| 30. |
87024930
|
[2] |
WASHER,10.8mm ID x 50mm OD x 3mm Thk
|
GI
|
| 31. |
86512446
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 32. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 33. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 34. |
331233
|
[8] |
PLUG
|
ZED
|
| 35. |
336455
|
[6] |
PLUG
|
ZED
|
