凯斯零件查询(LB424S XL) - BALER (11/16-) (31.220.070) - MAIN GEARBOX, HOUSING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
693 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47359647
|
[1] |
GEARBOX
|
ZED
Incl 2 - 10, Fig. 31.220.080 - 31.220.110, Serial Range: -C144 Superseded by part number: 47830517, 47560768
|
| 1. |
47560768
|
[1] |
GEARBOX
|
ZED
Incl 2 - 10, Fig. 31.220.080 - 31.220.110, Start Serial: D145
|
| 2. |
87688230
|
[1] |
BREATHER
|
ZED
|
| 3. |
84074433
|
[1] |
PLUG
|
ZED
Incl Washer
|
| 4. |
84346581
|
[1] |
PLUG
|
ZED
|
| 5. |
47360991
|
[1] |
GEARBOX
|
ZED
, Serial Range: -C144
|
| 5. |
47706722
|
[1] |
HOUSING
|
ZED
, Start Serial: D145
|
| 6. |
84074461
|
[17] |
STUD,M14 x 68mm, Cl 12.9
|
ZED
|
| 7. |
140030
|
[17] |
LOCK WASHER,M14
|
ZED
Superseded by part number: 80140047
|
| 8. |
87564740
|
[17] |
NUT
|
WIC
|
| 9. |
84000778
|
[2] |
SPINDLE
|
ZED
Superseded by part number: 944004907
|
| 10. |
84346514
|
[1] |
COVER
|
ZED
|
| 11. |
9837787
|
[8] |
BOLT,Hex, M24 x 200mm, Cl 8.8
|
ZED
|
| 12. |
9818872
|
[8] |
WASHER,25.3mm ID x 40mm OD x 5mm Thk
|
ZED
|
| 13. |
9837788
|
[8] |
NUT,M24 x 3, Cl 8.8
|
ZED
|
