凯斯零件查询(LB424S XL) - BALER (11/16-) (33.202.025) - HYDRAULIC BRAKES, TANDEM AXLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
265 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87492507
|
[1] |
FLEXIBLE HOSE,7.92mm ID x 2500mm L, SAE 100R1
|
ZED
|
| 2. |
87493575
|
[1] |
NUT
|
ZED
|
| 3. |
395019
|
[1] |
HYD CONNECTOR,M18 x 1.5 ORB x M16 x 1.5 ORB
|
PA
|
| 4. |
9839028
|
[1] |
HYD CONNECTOR,M18 x 1.5
|
PA
|
| 5. |
433008
|
[4] |
CLAMP
|
NH
|
| 6. |
395472
|
[3] |
3 WAY CONNECTION,M16 x 1.5 x M16 x 1.5 x M16 x 1.5
|
ZED
|
| 7. |
48014944
|
[1] |
HYD TUBE
|
ZED
|
| 8. |
48014946
|
[1] |
HYD TUBE
|
ZED
|
| 9. |
433101
|
[2] |
SUPPORT
|
NH
|
| 10. |
120056
|
[2] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
|
| 11. |
87716662
|
[2] |
NUT
|
ZED
|
| 12. |
430356
|
[2] |
CLAMP
|
ZED
|
| 13. |
84814948
|
[1] |
SUPPORT
|
ZED
|
| 14. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 15. |
338413
|
[2] |
BOLT,Hex, M6 x 60mm, Cl 8.8
|
NH
|
| 16. |
433007
|
[2] |
CLAMP
|
ZED
|
| 17. |
433100
|
[1] |
SUPPORT
|
ZED
|
| 18. |
48035585
|
[2] |
HYDRAULIC HOSE
|
ZED
|
| 18. |
48006691
|
[2] |
HYDRAULIC HOSE
|
ZED
|
| 19. |
47371203
|
[2] |
HYDRAULIC HOSE,7.92mm ID x 1260mm L, SAE 100R16
|
ZED
|
| 19. |
47995921
|
[2] |
HYDRAULIC HOSE
|
ZED
|
| 20. |
86590413
|
[2] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 21. |
445395
|
[2] |
RIVET,Pop, 4.8mm OD x 18.1mm L
|
IH
|
| 22. |
48031095
|
[1] |
HYDRAULIC HOSE
|
ZED
|
| 23. |
9507811
|
[1] |
CONDUIT
|
CUR
Superseded by part number: 9507811BR
|
| 24. |
2928203
|
[4] |
SOCKET
|
BER
|
| 25. |
84078124
|
[1] |
HYD CONNECTOR,9/16" - 18 JIC x M16 x 1.5
|
ZED
|
| 26. |
84449335
|
[16] |
CABLE TIE,346mm L
|
ZED
|
| 27. |
86588450
|
[2] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| 28. |
412152
|
[2] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
