| 1. |
48040291
|
[1] |
SUPPORT
|
ZED
|
| 2. |
9512544
|
[1] |
BRAKE VALVE
|
ZED
Superseded by part number: 87019852
|
| 3. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 4. |
140045
|
[12] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 5. |
100016
|
[12] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 6. |
9512529
|
[11] |
O-RING
|
PA
|
| 7. |
9512530
|
[11] |
WASHER, THRUST,22mm ID x 27mm OD x 2.6mm Thk
|
PA
Superseded by part number: 3076153R1
|
| 8. |
9512523
|
[2] |
PLUG
|
PA
|
| 9. |
9512525
|
[4] |
ELBOW
|
PA
|
| 10. |
84415666
|
[2] |
PLATE
|
ZED
|
| 11. |
84414378
|
[2] |
CLAMP
|
ZED
|
| 12. |
84036945
|
[1] |
AIR RESERVOIR
|
ZED
|
| 13. |
84415680
|
[1] |
BRACKET
|
ZED
|
| 14. |
9512528
|
[2] |
HYD CONNECTOR
|
PA
|
| 15. |
9512545
|
[2] |
AIR FILTER
|
PA
|
| 16. |
9512535
|
[4] |
HOSE
|
PA
Superseded by part number: 87359227
|
| 17. |
84014198
|
[2] |
HOSE,18mm OD x 3.5mm Thk
|
ZED
Superseded by part number: 87389513
|
| 18. |
9512531
|
[2] |
HYD CONNECTOR
|
PA
|
| 19. |
150064
|
[4] |
CLAMP
|
ZED
|
| 20. |
9512527
|
[7] |
FERRULE
|
PA
|
| 21. |
9512532
|
[1] |
O-RING
|
PA
|
| 22. |
9512533
|
[1] |
WASHER, THRUST,16.1mm ID x 22mm OD x 2.6mm Thk
|
PA
|
| 23. |
84007190
|
[1] |
ELBOW,M16 x 1.5 Male
|
ZED
|
| 24. |
48027370
|
[1] |
COUPLING
|
ZED
|
| 25. |
9512546
|
[1] |
COUPLING BLOCK
|
PA
|
| 26. |
9512537
|
[1] |
COUPLING BLOCK
|
PA
|
| 27. |
9507812
|
[3] |
CONDUIT
|
CUR
Superseded by part number: 9507812BR
|
| 28. |
86633356
|
[4] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 29. |
308761
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 30. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 31. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 32. |
43139
|
[4] |
BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
Superseded by part number: 11106231
|
| 33. |
84352951
|
[1] |
CLAMP
|
ZED
|
| 34. |
9512534
|
[2] |
HYD CONNECTOR
|
PA
|
| 35. |
86566990
|
[10] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 36. |
9512541
|
[1] |
DRAIN PLUG
|
PA
|
| 37. |
9512540
|
[1] |
HYD CONNECTOR
|
PA
Superseded by part number: 443287A1
|
| 38. |
378246
|
[2] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 39. |
412126
|
[2] |
NUT,M12 x 1.75
|
ZED
|
| 40. |
86590413
|
[2] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 41. |
445395
|
[3] |
RIVET,Pop, 4.8mm OD x 18.1mm L
|
IH
|
| 42. |
87716662
|
[1] |
NUT
|
ZED
|
| 43. |
86639002
|
[1] |
CLAMP,34.9mm, Coat, 11.9mm Bolt Hole, P Type
|
FAR
|
| 44. |
87029955
|
[1] |
CLAMP,22.2mm, Coat, 10.3mm Bolt Hole, P Type
|
WIC
|
| 45. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 46. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
Superseded by part number: 47560081, 47560080
|
| 47. |
140182
|
[1] |
WASHER,5.5mm ID x 18mm OD x 2mm Thk
|
ZED
|
| 48. |
43118
|
[1] |
BOLT,Hex, M6 x 1.0 x 40mm, Cl 8.8
|
NH
Superseded by part number: 120102
|
