凯斯零件查询(LB424S XL) - BALER (11/16-) (39.110.010) - LOW HITCH FRAME Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
996 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87531929
|
[1] |
DRAWBAR
|
ZED
|
| 2. |
84128880
|
[1] |
SUPPORT
|
ZED
|
| 3. |
87532958
|
[1] |
BRACKET
|
ZED
|
| 4. |
84056523
|
[16] |
BOLT,Hex, M16 x 45mm, Cl 10.9
|
ZED
|
| 5. |
140048
|
[22] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 6. |
392530
|
[16] |
NUT,M16, Cl 10
|
NH
|
| 7. |
86508584
|
[6] |
BOLT,Hex, M16 x 170mm, Cl 8.8
|
ZED
|
| 8. |
100020
|
[6] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 9. |
308761
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 10. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 11. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 12. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
