凯斯零件查询(LB424S XL) - BALER (11/16-) (39.110.070) - HITCH STEP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
562 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84555509
|
[1] |
STEP
|
ZED
|
| 1. |
48026653
|
[1] |
|
STEP
|
| 2. |
84555510
|
[1] |
STEP
|
ZED
, Serial Range: -C084 Superseded by part number: 47412381
|
| 2. |
47412381
|
[1] |
STEP
|
ZED
, Start Serial: D085
|
| 2. |
48026645
|
[1] |
|
STEP
|
| 3. |
374895
|
[2] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
, Serial Range: -C084
|
| 3. |
120044
|
[2] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
, Start Serial: D085
|
| 4. |
81541
|
[2] |
WASHER,0.5" ID x 1.25" OD x 0.08" Thk
|
NH
, Serial Range: -C084
|
| 4. |
140175
|
[4] |
WASHER,13.2mm ID x 25mm OD x 1mm Thk
|
ZED
, Start Serial: D085
|
| 5. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
, Serial Range: -C084
|
| 5. |
412126
|
[2] |
NUT,M12 x 1.75
|
ZED
, Start Serial: D085
|
| 6. |
9670066
|
[3] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 7. |
9804279
|
[3] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 8. |
84335923
|
[1] |
PIN,12.75mm OD
|
GI
|
| 9. |
596127
|
[1] |
SPRING,38.1mm Free Length
|
PA
|
| 10. |
300865
|
[1] |
LOCK PIN,M3 x 20mm OAL, Slotted
|
NH
Superseded by part number: 80300865
|
| 11. |
87528989
|
[1] |
WASHER,12.2mm ID x 30mm OD x 2.5mm Thk
|
BN
, Serial Range: -C084
|
| 11. |
87016607
|
[1] |
WASHER,13.5mm ID x 37mm OD x 3mm Thk
|
PLO
, Start Serial: D085
|
