| 1. |
47554088
|
[1] |
WIRE HARNESS
|
ZED
Incl Fig 55.640.011, Serial Range: -C150
|
| 1. |
47972521
|
[1] |
WIRE HARNESS
|
ZED
Incl Fig 55.640.011, Start Serial: D151
|
| 1. |
47966442
|
[1] |
WIRE HARNESS
|
ZED
Incl Fig 55.640.011
|
| 2. |
47554091
|
[1] |
WIRE HARNESS
|
ZED
|
| 3. |
47635778
|
[1] |
WIRE HARNESS
|
ZED
|
| 4. |
86523197
|
[1] |
SENSOR
|
ZED
B016 - Sensor Density Pressure
|
| 5. |
84391774
|
[1] |
SENSOR
|
ZED
B013 - Sensor Stuffer Trip
|
| 6. |
87342073
|
[1] |
SENSOR
|
GI
Bxxx - Knotter Lock Sensor
|
| 7. |
84353558
|
[2] |
SENSOR
|
ZED
B022/B023 - Right/Left Crop Sensor
|
| 11. |
87105683
|
[1] |
CAP
|
GI
|
| 12. |
84191453
|
[2] |
SOCKET,12/24V, 20A
|
DUB
|
| 13. |
84058832
|
[4] |
CLIP
|
ZED
, Serial Range: -C150
|
| 13. |
87716495
|
[1] |
CLAMP
|
BU
, Start Serial: D151
|
| 14. |
291186
|
[3] |
PROTECTION STRIP,9.9mm W
|
NH
, Start Serial: D145 Superseded by part number: 47560081, 47560080
|
| 15. |
86590413
|
[1] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 16. |
86625036
|
[3] |
CLAMP,12.7mm, Coat, 8.7mm Bolt Hole, P Type
|
FAR
|
| 17. |
858956
|
[1] |
CLAMP,11.1mm, Coat, 8.7mm Bolt Hole, P Type
|
NH
|
| 18. |
9706748
|
[3] |
CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type
|
NH
|
| 19. |
87307884
|
[1] |
CLAMP,27mm, Coat, 8.7mm Bolt Hole, P Type
|
ZED
|
| 20. |
86050346
|
[1] |
CLAMP,9.5mm, Coat, 7.1mm Bolt Hole, P Type
|
WIN
|
| 21. |
87612756
|
[1] |
CLAMP,25.4mm, Coat, 7.1mm Bolt Hole, P Type
|
PLO
, Serial Range: -C144
|
| 21. |
9837593
|
[1] |
CLAMP
|
ZED
, Start Serial: D145
|
| 22. |
87029955
|
[1] |
CLAMP,22.2mm, Coat, 10.3mm Bolt Hole, P Type
|
WIC
|
| 23. |
675162
|
[2] |
WIRE CLAMP,6.3mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 24. |
86566990
|
[1] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 25. |
445394
|
[1] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 26. |
9512290
|
[2] |
RIVET,Pop, 4.8mm OD x 17.8mm L
|
ZED
|
| 27. |
9824326
|
[1] |
WASHER,5.3mm ID x 10mm OD x 1mm Thk
|
NH
|
| 28. |
9512289
|
[1] |
RIVET,Pop, 4.8mm OD x 20.7mm L
|
PLO
, Start Serial: D145
|
| 29. |
322357
|
[6] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 30. |
9824259
|
[2] |
WASHER,6.4mm ID x 12mm OD x 1.6mm Thk
|
NH
|
| 31. |
140182
|
[1] |
WASHER,5.5mm ID x 18mm OD x 2mm Thk
|
ZED
|
| 32. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 33. |
120100
|
[1] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 34. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 35. |
120101
|
[1] |
BOLT,Hex, M6 x 1 x 30mm, Cl 8.8
|
NH
Superseded by part number: 87317695
|
| 36. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 37. |
412152
|
[1] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 38. |
412250
|
[1] |
NUT,M8 x 1.25, Cl 8
|
WIN
Superseded by part number: 86528579
|
| 39. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 40. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 41. |
401266
|
[1] |
STRIP-GASKET
|
ZED
, Serial Range: -C144
|
| 48. |
84322203
|
[1] |
CLIP
|
BUR
|
