神钢零件查询(K907) - MARK II EXCAVATOR ASN YN2956 (GLOBAL) (1/88-12/03) (08-011) - PARTS KIT (AIR CONDITIONER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
944 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100U346F2 | [1] | PARTS KIT | |
| 1. | 24100U346S1 | [1] | HOSE, SUCTION | HOSE, SUCTION |
| 9. | 24100U346S9 | [1] | CLAMP | |
| 10. | 24100U346S10 | [1] | CLAMP | |
| 11. | 24100U347S6 | [1] | PULLEY | KOB |
| 13. | 24100U346S13 | [3] | INSULATOR | |
| 14. | 24100U346S14 | [2] | INSULATOR | |
| 15. | 24100U346S15 | [10] | CLIP | |
| 16. | 24100U346S16 | [2] | BAND | |
| 17. | 24100U346S17 | [1] | BELT | KOB Superseded by part number: R06T0037D9 |
| 18. | 24100U346S18 | [2] | PACKING | |
| 19. | 24100U346S19 | [2] | BUSHING | |
| 20. | 24100U346S20 | [1] | CLAMP | |
| 21. | 24100U346S21 | [1] | TANK | KOB |
| 23. | 24100U346S23 | [1] | FLEXIBLE HOSE | KOBHOSE |
| 27. | 24100U345S19 | [1] | COMPRESSOR ASSY | COMPRESSOR ASSY |
| 29. | 24100U346S29 | [1] | HOSE | |
| 30. | 24100U346S30 | [1] | FLEXIBLE HOSE | KOBHOSE |
| 31. | ZS13C06020 | [1] | CAPSCREW M06x1.0x20mm | CAPSCREW M06x1.0x20mm |
