现代零件查询R370LC-7 OIL LINEEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
977 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
26880-83C00
|
[1] |
PIPE-OIL RETURN A
|
|
| 2. |
21747-83070
|
[1] |
GASKET
|
|
| 3. |
11961-10201
|
[4] |
BOLT-W/WASHER
|
|
| 4. |
26890-83C00
|
[1] |
PIPE-OIL RETURN B
|
|
| 5. |
26861-83C00
|
[1] |
GASKET
|
|
| 7. |
26895-83600
|
[1] |
HOSE
|
|
| N8. |
14717-02700
|
[2] |
CLAMP-HOSE
|
|
| 9. |
26870-83C00
|
[1] |
PIPE-OIL T/C INLET
|
|
| 10. |
26893-83600
|
[1] |
BOLT-EYE
|
|
| 11. |
17512-10000
|
[4] |
GASKET
|
|
| 12. |
31614-72000
|
[2] |
STAY
|
|
| 13. |
14833-06901
|
[6] |
CLAMP
|
|
| 14. |
11230-06301
|
[4] |
BOLT
|
|
| 15. |
31942-72000
|
[1] |
BOLT-EYE
|
|
| 16. |
17512-14000
|
[2] |
GASKET
|
|
